Running Options Rompaq From Diskettes; Creating Diskettes Using The Smart Array Controller Support Software Cd; Creating Diskettes Using The Smartstart Cd - Compaq 166207-B21 - Smart Array 5302/32 RAID Controller User Manual

8. When reprogramming of the controller ROM is finished, you can reprogram
more options or exit the utility.
— To reprogram another Compaq option, press the Enter key, and then repeat
steps 5 through 7.
— If you have finished reprogramming Compaq options, press the Esc key to
exit the utility.
9. Remove the CD and restart the server.

Running Options ROMPaq from Diskettes

To run Options ROMPaq from diskettes, first create Options ROMPaq diskettes from
one of the CDs or from the appropriate SoftPaq file.
Creating Diskettes Using the Smart Array Controller Support
Software CD
1. Insert the Smart Array Controller Support Software CD into the server CD-ROM
drive tray.
2. Open the OPTRMDSK folder on the CD and execute the QRST5.EXE file.
3. Follow the on-screen prompts to create the set of Options ROMPaq diskettes.
4. To complete the firmware update, follow the procedure given in the section,
"Using the Diskettes."

Creating Diskettes Using the SmartStart CD

1. Insert the SmartStart CD into the CD-ROM drive tray of a server with a bootable
CD-ROM drive.
2. Restart the server.
3. On the Compaq System Utilities screen, select Create Support Software.
4. On the Diskette Builder screen, scroll through the list and select Options
ROMPaq, and then click Next.
Compaq Smart Array 5300 Controller User Guide
Updating the Controller Firmware
5-3
