Summarization of Contents
Safety Warnings and Operation Modes
Ducted Mode
Connect the hood's motor outlet to an external fumes outlet.
Recirculation Mode
Use anti-odour carbon filters to filter and recycle air.
Installation Instructions
Mounting Distances and Motor Intake
Specifies minimum distances and motor intake assembly.
Hood Installation Steps
Details on centering, fixing supports, drilling, and leveling.
Ducted Mode Installation
Connect motor outlet to ducting, remove carbon filter if present.
Recirculation Mode and Chimney Assembly
Recirculation Mode Setup
Install active carbon filters for air recirculation.
Chimney Assembly
Adjust, block, and fix telescopic chimneys and bracket.
Control Panel Operation
Slider Control Panel
Operating light and speed with slider and cursor.
Electromechanical Pushbuttons
Using buttons for light, motor off, and speed adjustment.
Knob Control Panel
Operating light and speed with knobs.
Optional Functions and Filter Warnings
Electronic Pushbuttons
Controls for lights, speed, and filter reset.
Auto Power-Off Timer
Activates automatic motor and light shut-off after 10 minutes.
Filters Cleaning Warning
Alert for cleaning/replacing filters when LEDs blink.
Cleaning and Maintenance
General Cleaning Advice
Disconnect power; use damp cloth with non-bleach detergent.
External Cleaning
Clean with damp cloth, avoid solvents/abrasives; rub with the grain.
Filter Maintenance
Metal Filters Cleaning
Clean metal grease filters monthly or more often.
Carbon Filters Replacement
Replace carbon filters every six months or as needed.
Lights Replacement
Incandescent Lamp Replacement
Replace E14 40W 230V lamps by unscrewing fixture and lamp.
Halogen Lamp Replacement
Replace G4 20W 12V lamps using a screwdriver.
Biax Neon Lamp Replacement
Replace G23 11W biax lamps after removing the fixture.
Neon Tube Replacement
Replace 15/18W neon tubes by removing glass framework.
Warranty and Technical Assistance
Customer Service Contact
Provides phone numbers and required data for service.
