- Page 1 Libretto Istruzioni Instruction Manual Manuel d’Instructions Bedienungsanleitung Gebruiksaanwijzing Manual de Instrucciones KSEIV97X...
- Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood. - Page 4 CHARACTERISTICS Dimensions...
- Page 5 Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Telescopic Chimney comprising: Upper Section Lower Section Telescopic frame complete with extractor, consisting of: 7.1a Upper frame 7.1b Lower frame Right Air Outlet Grill Left Air Outlet Grill Damper Hood Body Air Outlet Extension Piece consisting of two Half Shells...
-
Page 6: Installation
INSTALLATION Drilling the Ceiling/shelf and fixing the frame • Use a plumb line to mark the centre of the hob on the ceiling/support shelf. • Place the drilling template 21 provided on the ceiling/support shelf, making sure that the template is in the correct position by lining up the axes of the template with those of the hob. -
Page 7: Ducted Version Air Exhaust System
Upper frame • Align the power supply cable feed hole • Fix the upper frame to the ceiling or shelf using: • For concrete ceilings, use the appropriate plugs for the screw size (not provided). • For hollow brick ceilings of wall thickness of approximately 20 mm: use 4 plugs 11 and 4 screws 12h (5,2 x 70), provided. -
Page 8: Electrical Connection
Flue assembly - Mounting the hood body • Position the upper chimney section and fix the upper part to the frame using the 2 screws 12c (2,9 x 6,5) provided. • Similarly, position the lower chimney section and fix the lower part to the frame using the 2 screws 12c (2,9 x 6,5) provided. -
Page 9: Control Panel
Light Switches the lighting system on and off. S 1 Led Motor running led. It flashes once after 100 working hours of the hood to indicate that the grease filters need washing. It flashes twice after 200 working hours to indicate that the grease filters need washing and that the anti-odour charcoal filters, if any, need changing. -
Page 10: Maintenance
MAINTENANCE CLEANING METAL SELF- SUPPORTING GREASE FILTERS Alarm signal reset • Switch off the lights and extractor motor. • Press button V2 for at least 3 seconds, until the leds start to flash. Cleaning the filters • The filters must be cleaned when led S1 flashes or at least every 2 months of operation, or more frequently for particularly heavy usage. -
Page 11: Activated Charcoal Filter (Recirculation Version)
Activated charcoal filter (Recirculation version) REPLACING THE ACTIVATED CHARCOAL FILTER • The filter is not washable and cannot be regenerated. It must be replaced when led S1 flashes twice or at least every 4 months. The alarm signal will only light up when the extractor motor is switched on. - Page 12 Quest’apparecchio è conforme alla norma europea sulla bassa tensione C.E.E. 73/23 relativa alla sicurezza elettrica e alle norme europee: C.E.E. 89/336 relativa alla compatibilità elettromagnetica e C.E.E. 93/68 relativa alla marcatura CE. This appliance conforms to European Low Voltage Directive 73/23/CEE governing electrical safety, European Directive 89/ 336/CEE on Electromagnetic Compatibility and Directive 93/68/CEE regarding CE Marking.
