- Page 1 Libretto istruzioni User manual Manuel d’Instructions Bedienungsanleitung Gebruiksaanwijzing Manual de instrucciones Manual de Instruções Brugsvejledning Bruksanvisning Руководство по эксплуатации Instrukcja Obsługi Bruksanvisning KSET6XE - KSET9XE...
- Page 2 INDICE CONSIGLI E SUGGERIMENTI.............................. 5 CARATTERISTICHE................................6 INSTALLAZIONE ................................... 8 USO...................................... 10 MANUTENZIONE ................................11 INDEX RECOMMENDATIONS AND SUGGESTIONS ........................12 CHARACTERISTICS ................................13 INSTALLATION..................................15 USE ...................................... 17 MAINTENANCE ................................... 18 SOMMAIRE CONSEILS ET SUGGESTIONS............................19 CARACTERISTIQUES................................. 20 INSTALLATION..................................22 UTILISATION ..................................
- Page 3 ÍNDICE CONSELHOS E SUGESTÕES............................47 CARACTERÍSTICAS ................................48 INSTALAÇÃO..................................50 UTILIZAÇÃO ..................................52 MANUTENÇÃO..................................53 INDHOLD RÅD OG ANVISNINGER ..............................54 APPARATBESKRIVELSE ..............................55 INSTALLATION..................................57 BRUG ....................................59 VEDLIGEHOLDELSE ................................60 INNEHÅLL REKOMMENDATIONER OCH TIPS ........................... 61 EGENSKAPER..................................62 INSTALLATION..................................
- Page 4 INNHOLD ANBEFALINGER OG FORSLAG ............................89 EGENSKAPER..................................90 INSTALLASJON................................... 92 BRUK ....................................94 VEDLIKEHOLD ..................................95...
- Page 5 RECOMMENDATIONS AND SUGGESTIONS The Instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation.
- Page 6 CHARACTERISTICS Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Directional Air Outlet grille Flange ø 120 mm Closing element Ref. Q.ty Installation Components Screws 3,5 x 16 Screws 2,9 x 12,7 Screws 2,9 x 9,5 Q.ty Documentation Instruction Manual 1 13...
- Page 7 Dimensions Min. Min. 650mm 650mm 1 14...
- Page 8 INSTALLATION Drilling the Support surface and Fitting the Hood • The Hood can be fitted directly on the lower surface of the Wall Units (650 mm min. above the Cooker Top) using the snap- on Side Supports. • Make an opening on the lower surface of the Wall Unit, as indicated.
- Page 9 Connections DUCTING VERSION AIR EXHAUST SYSTEM When installing the hood in ducting version, a rigid or a flexible pipe with the diameter corresponding to the flange diameter is used in order to connect the hood to the air outlet piping. •...
- Page 10 By pulling out the sliding panel it is possible to automatically activate all the hood functions. By simply closing the sliding panel all the functions are switched off. SWITCH FUNCTIONS Light Switches the lighting system on and off Motor Switches the extractor motor on and off 1.
- Page 11 MAINTENANCE Grease filters CLEANING METAL CASSETTE GREASE FILTERS • The filters must be cleaned every 2 months, or more frequently in case of particularly heavy use of the hood. Filters can be washed in a dishwasher. • Pull out the sliding suction panel. •...
