Add and name a layer

You'll now add a layer, name the layer, and then add a graphic symbol to the layer.
In the Timeline, click the Car layer.
1.
Click the Insert Layer button below the Timeline.
2.
The new layer appears above the Car layer and becomes the active layer.
Double-click the layer name, type Background as the new name for the layer, and press Enter
3.
(Windows) or Return (Macintosh).
As a best practice, always name each layer, and give the layer a meaningful name that indicates
the type of content on the layer.
In the Library panel (Window > Library), select the background graphic symbol and drag it to
4.
the Stage.
Because the Background layer is above all layers except the Mask layer, objects on that layer
appear over objects on lower layers.

Change the order of layers

Obviously, you don't want the background to cover the other objects on the Stage. Normally, the
background layer is the bottom layer on the Timeline. You'll move the Background layer you
just created.
In the Timeline, drag the Background layer from the top position to the bottom position.
1.
All objects on the Stage now appear on top of the background.
With the Background layer still selected, in the Property inspector, enter 0 in the X text box
2.
and 72 in the Y text box. Press Enter or Return to precisely position the Background layer on
the Stage.

Organize layers in a folder

You can create layer folders to organize layers and reduce Timeline clutter. The Timeline contains
two layers that contain navigation objects: one for navigational buttons and another for
navigational art. You'll create a layer folder, named Navigation, for both layers.
In the Timeline, select the Buttons layer.
1.
Click the Insert Layer Folder button, which is below the layer names.
2.
Note: If the Property inspector shows properties for the frame rather than for the movie clip, click
the Background movie clip on the Stage.
Double-click the layer folder name and rename the folder Navigation.
3.
Drag the Navbar layer and the Buttons layer to the Navigation folder.
4.
The layers appear indented to indicate that they're within the folder.
You can click the expander arrow to expand and collapse the folder and included layers.
44 Chapter 5: Work with Layers
