Summarization of Contents
Prepare for Installation
Verify Received Hardware
Ensure all required hardware components and cables are present in the received package.
Gather Required Tools
Collect necessary tools such as screwdrivers, a flashlight, and an ESD strap for the installation.
Install the Hardware
Pre-installation Procedures
Prepare a static-free work area, register hardware, and obtain an ESD wristband.
Install Rack Rails
Mount the appropriate rails into the rack or cabinet according to provided instructions.
Mount Drive Shelf
Safely mount the drive shelf onto the installed rails within the rack or cabinet.
Secure the Shelf
Fasten the shelf to the rack using screws and back brackets for stability.
Install Bezel and End Caps
Attach the front bezel and end caps to the controller and drive shelves.
Connect and Power Devices
Cable the Shelves
Connect SAS cables between controller and drive shelves as per configuration.
Power Drive Shelves
Connect power cables and turn on drive shelves before the controller shelf.
Configure Storage System
Cable Data Hosts
Connect data hosts to the storage array using direct-attach or fabric topology.
Configure Management via DHCP
Set up network management using a DHCP server for controller IP assignment.
Configure Management via Static IP
Manually configure controller management ports with static IP addresses.
Finalize System Setup
Use SANtricity software to configure and manage storage arrays and access System Manager.
