Electrolux EW30CC55GW - 30in Electric Cooktop Dimension Manual

30" induction hybrid cooktops
Hide thumbs


Advertisement

Induction Hybrid Cooktops
EW30CC55G S, EW30CC55G W, EW30CC55G B
Boil Water in 90 Seconds
Induction technology is more responsive than
gas or electric, and the Power Assist function
generates rapid heat, so you can bring water
to a boil quickly – in 90 seconds!
More Energy-Efficient
Cooking with induction is 70% more efficient
than gas and 20% more efficient than electric.
10" and 6" Induction Elements
With two powerfully efficient induction
elements, plus up to three electric elements,
the Induction Hybrid Cooktop offers the
utmost cooking flexibility. And the 10" induction
element offers 3,400 watts of power, so you
can bring water to a boil quickly.
Exceptional Temperature Control
Adjust heat with greater accuracy than gas
or electric cooktops, especially at lower
settings. Perfect for melting chocolate and
cooking delicate foods and sauces.
30" INDUCTION HYBRID COOKTOPS
Features
Perfect Set
Ceramic Smoothtop Glass Surface
6" to 9" Dual Expandable Element – 1600W / 3000W
6" Electric Element – 1200W
10" Induction Cooking Element – 2500W / 3400W
6" Induction Cooking Element – 1500W / 1900W
Hot Surface Indicator Lights
Sealed Spill Control Cooktop
Sabbath Mode (Star-K
A.D.A. Compliant*
Accessories
Granite Countertop Installation Kit – PN # 903061-9010
Cleaning Sponge
Griddle Plate – PN # 318251611
Specifications
Color –
Stainless Steel
White
Black
Product Dimensions –
Width
Depth
Height (Extreme Bottom to Underside of Cooktop)
Power Supply Connection Location
Connected Load (kW Rating) @ 240 / 208 Volts
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
1
Electrical – Single phase 4-wire cable,
120 / 240 Volts or 120 / 208 Volts, 60 Hz,
fused on both sides of line with ground.
Armored Electrical Cable
Approved for Single Oven Combination Installation**
Approved for Downdraft Combination Installation**
Shipping Weight (Approx.)
*When properly installed, meets the appliance standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility Guidelines as published by the United States
Access Board on June 23, 2004, as amended August 5, 2005.
NOTE: Always consult local and national electric codes. Refer to Product Installation Guide
for detailed installation instructions on the web at electroluxappliances.com.
Specifications subject to change.
**Approved to be used over any Electrolux Single Wall Oven
OR in combination with any Electrolux 30" Downdraft Vent.
1
10" induction element with Power Boost, 6 qt./10" diameter pot, 1 qt. tepid water.
®
Electronic Touch Controls
®
Certified)
electroluxappliances.com
Yes
Yes
1
1
1
1
Yes
Yes
Yes
Yes
Optional
Included
Optional
S
W
B
30-3/4"
21-3/4"
6-1/2"
Right Center Rear
8.1 / 7.1
33.8 / 34.1
40
Required
Included
Yes
Yes
62 Lbs.
