Major operating controls

Monitor out
connector for
adjustment
(RCA jack)
View from the side
Panning lock screw [LOCK]
* This connector is provided only for service. Do not use the connector for checking the adjust-
ment of the angular field of view on the video monitor.
16
(Provided only for service)
Monitor out connector for
service*
Marker
MONITOR
OUT
LOCK
Panning table
Dome cover
Inner dome
Clear dome
Direction marker for installation
Azimuth adjustment ring
FRONT
TOP
BASE-T/
BASE TX
TOP
12V IN
Tilting table
12 V DC power supply
terminal
