TRENDnet TV-H400 Quick Installation Manual

TRENDnet TV-H400 Quick Installation Manual

Quick installation guide
Hide thumbs Also See for TV-H400:

Advertisement

Quick Links

Download this manual See also: Quick Installation Manual
Quick Installation Guide
TV-H400
H/W: V1.0R

Advertisement

loading
Need help?

Need help?

Do you have a question about the TV-H400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet TV-H400

Summary of Contents for TRENDnet TV-H400

  • Page 1 Quick Installation Guide TV-H400 H/W: V1.0R...
  • Page 2 Table of Contents English ...................... 1 1. Before You Start ................2. Hardware Installation ................. Troubleshooting ..................9 Version 07.10.2008...

  • Page 3: English

    1. Before you start Package Contents TV-H400 Quick Installation Guide Power Adapter (12V DC, 0.6A) 1 x Ceiling Mounting Bracket Hexagon screwdriver (1/4” L=6mm) Screws and washers Rubber seal Installation Requirements The following items below are not included. Users must provide the items themselves.

  • Page 4: Hardware Installation

    2. Hardware Installation Note: Configure your Internet Camera Server to match your network before installing the device. 1. Rotate the TV-H400's cover counter clockwise and remove the cover. 2. Unscrew the thumbscrew to remove the protective plate from the wall mount. Save this screw.
  • Page 5 4. Run each cable through the opening located at the top of the TV-H400. DO NOT run all cables through the opening simultaneously. Serious blockage can occur. 5. After inserting the appropriate cables, extend each cable to 6 inches for camera installation.
  • Page 6 8. Screw the ceiling or wall mount on top of the TV-H400 with the provided Allen wrench and three hexagon socket screws. The screws are in the plastic bag labeled Q2 or Q2B. 9. Combine the 5cm Hex screws with the 1cm Hex screws.
  • Page 7 11. Mount the assembly in step 10 to the camera enclosure using the three flat head screws. These screws are in the plastic bag labeled Q1. 12. Mount this bracket on top of the three Hex screws, Then using the three round head screws to secure the bracket.
  • Page 8 14. Attach the mounting plate for the camera with 3 small screws. These screws should come with the Internet Camera Server. 15. Take the assembly in step 14 and mount the assembly on top of the mounting bracket with two round head screws.
  • Page 9 Your installation is now complete. For detailed information regarding the TV-H400 configuration and advanced settings, please visit TRENDnet's website at www.trendnet.com Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register...
  • Page 10 Mounting the Camera Enclosure Note: Mounting screws and screw anchors are not included. 1. Place the mounting bracket against the wall or ceiling and mark each of the four holes with a pencil. 2. Drill holes for the screws at each marked position.

  • Page 11: Troubleshooting

    What should I do? First, make sure that you have adjusted the focus on your camera. Second, mount the TV-H400 so that it's not in direct view of the sun. If you still encounter problems or have any questions regarding the TV-H400, please...
  • Page 12 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
  • Page 13 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2008. All Rights Reserved. TRENDnet.
