Quick Installation Guide
TV-H400
V3.0R

Advertisement

loading
Need help?

Need help?

Do you have a question about the TV-H400 and is the answer not in the manual?

Questions and answers

Related Manuals for TRENDnet TV-H400

Summary of Contents for TRENDnet TV-H400

  • Page 1 Quick Installation Guide TV-H400 V3.0R...
  • Page 2 Table of Contents English 1. Before You Start 2. Hardware Installation Troubleshooting Version 01.08.2011...

  • Page 3: System Requirements

    1. Before You Start Package Contents TV-H400 Ÿ Quick Installation Guide Ÿ Power Adapter (12V DC, 0.6A) Ÿ 4 x Enclosure Mounting Brackets Ÿ (BR001, BR002, BR003, BR004) 1 x Wall Mounting Bracket Ÿ 1 x Ceiling Mounting Bracket Ÿ...
  • Page 4 2. Hardware Installation Note: Configure your Internet Camera Server to match your network before installing the device. TV-IP612P Q6: Round Head Screw x 3 pcs Bracket: BR004 Q3: 5cm Hex Screw x 3 pcs Q1: Flathead screw Bracket: BR001 x 3 pcs Q5: Washer x 3 pcs Hex Nut Top x 3 pcs...
  • Page 5 TV-IP612P 1. Rotate the TV-H400's cover counter clockwise and remove the cover. 2. Remove three screws and remove the protective plating from the TV-H400. Save these screws. You will need to use these screws later. 3. Run all necessary cables (network cable, Power Adapter cable, and the power terminals) through the wall mount.
  • Page 6 5. Run the Ethernet cable and the IP Camera's power adapter cable through the opening located at the top of the TV-H400. 6. After inserting the appropriate cables, extend each cable to 6 inches for camera installation. 7. Use the provided rubber seal to seal the...
  • Page 7 8. Secure the protective plating into the wall mount bracket using the thumb screw. 9. Screw the wall mount bracket on top of the TV-H400 with the provided Allen wrench and three hexagon socket screws. The screws are in the plastic bag labeled Q2B.
  • Page 8 11. Mount bracket BR003 to the camera enclosure using the three flat head screws. These screws are in the plastic bag labeled 12. Use three round head screws to mount the metal bracket BR004 on top of the 3 Hex screws.
  • Page 9 16. Place the TV-H400's cover over the camera and rotate the cover clock-wise. 17. Plug the power to the IP Camera and the camera enclosure into an available power outlet.
  • Page 10 TV-IP410/TV-IP600...
  • Page 11 1. Rotate the TV-H400's cover counter clockwise and remove the cover. 2. Remove three screws and remove the protective plating from the TV-H400. Save these screws. You will need to use these screws later. 3. Run all necessary cables (network cable, Power Adapter cable, and the power terminals) through the wall mount.
  • Page 12 4. Connect the TV-H400 power terminal to the provided 12V DC, 0.6A power adapter. 5. Run the Ethernet cable and the IP Camera's power adapter cable through the opening located at the top of the TV-H400. 6. After inserting the appropriate cables, extend each cable to 6 inches for camera installation.
  • Page 13 9. Screw the wall mount bracket on top of the TV-H400 with the provided Allen wrench and three hexagon socket screws. The screws are in the plastic bag labeled Q2B. 10. Connect the three 5 cm Hex screws to the circular base bracket.
  • Page 14 12. Use three round head screws to mount bracket BR002 on top of the 3 Hex screws. The three round head screws are in the plastic bag labeled Q6. 13. Connect the two 3 cm hex screws to this bracket. These screws are in the plastic bag labeled Q4.
  • Page 15 16. Connect the network cable and power adapter to the IP Camera. 17. Place the TV-H400's cover over the camera and rotate the cover clock-wise. 18. Plug the power to the Internet Camera Server and the camera enclosure into an available...
  • Page 16 Mounting the Camera Enclosure Note: Mounting screws and screw anchors are not included. 1. Place the mounting bracket against the wall or ceiling and mark each of the four holes with a pencil. 2. Drill holes for the screws at each marked position.
  • Page 17 1. After I put my IP Camera in the enclosure, the image is distorted. What should I Make sure that you have adjusted the focus on your camera. 2. Mount the TV-H400, so that it's not in direct view of the sun. 2. Does the TV-IP422 and TV-IP422W work with the TV-H400? We do not recommend using the TV-IP422 and TV-IP422W with the TV-H400.
  • Page 18 TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment.
  • Page 19 Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt...
  • Page 20 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
  • Page 21 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register Copyright ©2011. All Rights Reserved. TRENDnet.
