5. API for Acquiring/Changing Parameters of VN-E4 _
5.4. Alarm Setting
The APIs below are related to alarm setting. These are equivalent to the features on the Alarm page of the WEB setting page. Refer to the
instruction manual for details on the Alarm page.
Acquiring Alarm On/Off Status from VN-E4
Format
Example
Example of response
Interpretation
Setting Alarm to Off for VN-E4
Format
Example
Example of response
Interpretation
Acquiring JPEG Parameters Added to FTP from VN-E4
Format
/api/param?application.event(Number).status
When acquiring the on/off status of Encoding No. 1
/api/param?application.event(1).status
application.event(1).status=on&200 OK
Acquire the on/off status of the alarm action for the specified encoding number. Up to 10 alarm actions can be
specified, and therefore the number of event(Number) can also be set between the range of 1 to 10. Note that
alarm numbers are different from the alarm input pin numbers.
Either on or off will be returned.
/api/param?application.event(Number).status=off
When setting Alarm No. 1 to off
/api/param?application.event(1).status=off
application.event(1).status&200 OK
Set the alarm action of the specified encoding number to off. When this is set to off, the action that is
associated with this event will be deleted. When it is an FTP action, the object (file attribute that is sent via
FTP) will also be deleted. Up to 10 alarm actions can be specified, and therefore the number of event(number)
can also be set between the range of 1 to 10. Note that alarm numbers are different from the alarm input pin
numbers.
This API cannot be used to turn on the alarm action. To turn on the alarm action, specify a specific action using
the API for setting the alarm action.
As mentioned in the section on acquiring/setting alarm actions, specify between object01 to object08 for JPEG
to be added to FTP. Each object is a combination of the input CH and frame size as indicated below.
Object
Input CH
object01
1
object02
1
object03
2
object04
2
object05
3
object06
3
object07
4
object08
4
Frame rate, BeforeTrigger and AfterTrigger for FTP are common among all objects. A same value will be
returned during acquisition by any of the objects.
Acquisition of input CH:
Acquisition of frame size:
Acquisition of frame rate:
Acquisition of BeforeTrigger: /api/param?application.object(Number).prerec
Acquisition of AfterTrigger:
Frame Size
VGA
QVGA
VGA
QVGA
VGA
QVGA
VGA
QVGA
/api/param?application.object(Number).source
/api/param?application.object(Number).framesize
/api/param?application.object(Number).framerate
/api/param?application.object(Number).postrec
5.4. Alarm Setting
27
