ROSE DISPLAYS SUPERSNAP WITH SLATWALL HANGERS Instruction Sheet

SuperSnap™

Parts

Instructions for assembly

Step 1

Snap the SuperSnap open and insert
poster (top and bottom). Fig. 1
Note: It is easier to open and close the
SuperSnap by starting at one end and
working your way down the holder.

Step 2

To close, snap the SuperSnap shut. Fig.
2

Step 3

Insert hangers into upper portion
of slatwall. Hangers will rest on lower
portion of slatwall. Fig. 3
Note: To ensure that the SuperSnap
hangs level use two hangers placed an
equal distance in from each side of the
frame.

Step 4

Place the SuperSnap on the hangers
using the bottom channel of the top rail.
Fig. 4

Step 5

Push end caps into place. Fig 5

Important note:

Please save and reuse the
SuperSnap, Slatwall hangers and
End Caps for future projects.
The SuperSnap™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSSuperSnapSlatwall
Incept-7.05.02
Instruction Sheet
SuperSnap
SuperSnap Slatwall Hangers
12S300
End Caps
06-6068S 06-5475
Figure 1
Figure 3
Figure 4
Figure 2
Figure 5
