Summarization of Contents
Safety Instructions for the Users
General Safety Regulations
Covers fundamental rules for tractor operation and user conduct.
Proper Clothing
Specifies appropriate attire and personal protective equipment for safe operation.
Starting the Engine
Details critical steps and precautions for safely starting the tractor's engine.
Principles of Fire Safety
Outlines essential practices to prevent fire hazards during operation and maintenance.
Electric Installation Safety
Provides warnings and guidelines for safe handling of the tractor's electrical system.
Daily Preventive Maintenance
Tightness of the Fuel System
Instructions for checking fuel system integrity and eliminating leaks.
Level of Oil in the Engine
Procedures for checking engine oil level and lubrication system connections.
Cooling System Checks
Guidance on checking cooling system connections and coolant level.
Fluid Brakes Maintenance
Maintenance checks for fluid brakes, clutch fluid, and brake fluid level.
Hydrostatic Steering Checks
Procedures for checking oil level and condition of the hydrostatic steering system.
Tyres and Wheels Maintenance
Guidelines for checking tyre pressure and tightening wheel screws.
Air Cleaner Maintenance
Maintenance procedures for the air cleaner based on the clogging indicator.
Filtration of the Cab Air
Instructions for checking and cleaning air filters for the tractor cabin.
Suspension Equipment Checks
Procedures for checking the condition of suspension and connection equipment.
Short Functional Test
Steps to verify key system functions after starting the engine.
Getting to Know the Tractor
Safety Cabin Overview
Guidance on safe entry/exit and general cabin safety practices.
Dashboard Instruments
Description of instruments and indicator lights on the main dashboard.
Digital Dashboard Features
Explanation of indicators and pushbuttons on the digital dashboard display.
Controls: Switchers and Levers
Identification and function of various controls on the steering column and dashboard.
Ignition Box Operation
Details on ignition box positions and key functions for starting and operation.
Tractor Pedals
Identification and function of the tractor's main pedals.
Gear Shifting Lever
Explanation of the main shifting lever and gear selection process.
Torque Multiplier Operation
Operation and function of the two-stage torque multiplier system.
Hydraulics Control Panel
Overview of the controls for the tractor's hydraulic system.
Driving
Before Starting the Engine
Essential checks to perform before initiating tractor engine start.
Starting the Engine Procedure
Step-by-step procedure for starting the tractor's engine safely and correctly.
Immediate Post-Start Actions
Recommended actions and checks immediately following engine startup.
Engine Warming-up
Guidance on proper engine warming-up procedures to prevent damage.
Gear Shifting
Explanation of the tractor's gearbox, including gear shifting and multiplier operation.
Reversing Lever Operation
Instructions on using the reversing lever for forward and backward tractor movement.
Moving Off Safely
Detailed steps for safely moving the tractor from a standstill.
Foot Brakes Usage
Information on the tractor's foot brake system, including coupling and usage.
Stopping the Tractor with Hand Brake
Procedure for safely engaging the hand brake to stop the tractor.
Stopping the Engine
Correct steps for shutting down the tractor's engine after use.
Running-in the Tractor
General Principles for Initial Running-in
Key guidelines for the initial break-in period of a new tractor.
First 100 Operating Hours
Specific procedures for running-in during the initial 100 operating hours.
Transport Use
Multi-level Quick-Adjustable Hitch CBM
Description and use of the CBM hitch for trailers.
Automatic Hitch Operation
Operation of the automatic hitch mechanism for trailers.
Coupling Single-Axle Trailers
Steps for connecting a single-axle trailer to the tractor.
Coupling Trailers and Semi-Trailers
Procedures for connecting various types of trailers and semi-trailers.
Hitch Static Loading Limits
Specifications for the maximum vertical static load capacity of different hitch types.
Drive of Farming Machines
Working with Output Shaft
Essential precautions and procedures when working with the tractor's output shaft.
Control of Front and Rear Output Shafts
Instructions for engaging and disengaging front and rear output shafts.
Rear Output Shaft Speed Shifting
How to shift between dependent and independent speeds of the rear output shaft.
Selecting Rear Output Shaft Speeds
Procedures for selecting output shaft speeds (540, 1000, 540E RPM).
Front Output Shaft Details
Information on the front output shaft, including its terminal and rotation options.
Hydraulic Equipment
Hydraulic Pump Information
Details on the tractor's hydraulic pump, including its type and delivered volume.
Hydraulic Oil Filtration
Procedures for maintaining the hydraulic oil filtration system.
Hydraulic Control Functions
Overview of the functions of various hydraulic control levers.
Internal Hydraulic Circuits
Description of the tractor's internal hydraulic circuits and controls.
Internal Circuit Lever Operation
How the internal circuit lever controls implement lifting, height, and depth.
Lever of Options of Regulation
Explanation of the lever positions (P, M, D) for hydraulic regulation modes.
Lever of Speed of Response
How the speed lever adjusts oil flow distribution and response time.
External Hydraulic Circuits
Information on the external hydraulic circuits for connected implements.
External Circuit Lever Operation
Operation of the external circuit lever through its four positions.
Single-Acting Cylinder Control
Control procedures for single-acting hydraulic cylinders.
Double-Acting Cylinder Control
Control procedures for double-acting hydraulic cylinders.
Additional Hydraulic Distributor
Description of the additional hydraulic distributor and its sections.
Connecting Implements to External Hydraulics
Guidelines for connecting implements to the external hydraulic circuit.
Hitches
Rear Three-Point Hitch
Description and specifications of the rear three-point hitch system.
Safety with Three-Point Hitch
Crucial safety rules for working with implements attached to the three-point hitch.
Height Adjustment of Lifting Pull Rods
Procedures for adjusting the height of the lifting pull rods.
Lower Hydraulic Pull Rod Positions
Explanation of fixed and free positions for lower hydraulic pull rods.
Limiting Pull Rods
Function and adjustment of limiting pull rods for side swing control.
Upper Pull Rod Adjustment
Details on the adjustable upper pull rod and its connection points.
Bracket Hole Selection
How bracket hole selection affects hydraulic regulation sensitivity.
Lower Pull Bars with Extensible Terminals
Information on lower pull bars with semi-automatic extensible terminals.
Lower Pull Bars with CBM Hooks
Description of lower pull bars equipped with CBM hooks.
Front Three-Point Hitch
Description and purpose of the front three-point hitch system.
Front Three-Point Hitch Control
How to operate the front three-point hitch using hydraulic controls.
Adjusting Front Three-Point Hitch Speed
How to adjust the lowering speed of the front three-point hitch.
Change of Wheels Tread
Changing Front Wheels Tread
Steps for changing front wheel tread by adjusting rim and disk position.
Setting Front Axle Stops
Procedures for setting steering stops after changing front wheel tread.
Front Wheels Toe-in Measurement
Measurement and definition of front wheel toe-in for the driving axle.
Adjusting Toe-in on Front Driving Axle
Detailed steps for adjusting front wheel toe-in with hydrostatic steering.
Changing Rear Wheels Tread
Methods for adjusting rear wheel tread by changing rim and disk positions.
Additional Weights
Front Bonnet Mask Weights
Information on mounting front weights for improved tractor stability.
Front Three-Point Hitch Weights
Specifications for weights that can be mounted on the front three-point hitch.
Rear Wheels Weights
Details on mounting weights on rear wheels for better traction.
Tyre Fluid Filling Valve
Description of the valve used for filling tractor tyres with fluid.
Filling Tyres with Water Procedure
Step-by-step instructions for filling tractor tyres with water.
Draining Fluid from Tyres Procedure
Steps for safely draining fluid from tractor tyres.
Electric Installation
Electric System Overview
Overview of the tractor's electrical system specifications.
Essential Service Information
Critical safety and connection information for electrical system service.
Battery Location and Disconnector
Location and function of the tractor's battery and battery disconnector.
Battery Maintenance
Procedures for safe battery cleaning, fixing, and maintenance.
Alternator Information
Information on the alternator's location, function, and maintenance.
Alternator Maintenance
Precautions and guidelines for maintaining the alternator.
List of Tractor Lamps
A table detailing all tractor lamps, their locations, voltage, power, and socket type.
Tractor Maintenance
Daily Maintenance Operations
Daily pre-operation checks for engine, brakes, and systems.
100-Hour Maintenance Tasks
Maintenance tasks to be performed every 100 operating hours.
Replacement of Fillings and Filters
Schedule for replacing engine oil, filters, coolant, and brake fluid.
Fluid and Lubricant Amounts
Table specifying types and quantities of fluids and lubricants for the tractor.
Recommended Engine Oils
Recommended engine oils, viscosity classes, and API output classes.
Transmission Gearing Oils
Recommended oils for the tractor's transmission gearing, including viscosity and API classifications.
Front Drive Axle Oils
Recommended oils for the front drive axle system.
Hydrostatic Steering Oil
Recommended oils for the hydrostatic steering system.
Hydraulic Brake Fluids
Recommended fluids for the tractor's hydraulic brake system.
Cooling System Fluid
Recommended fluids and mixture ratios for the tractor's cooling system.
Fuel Recommendations
Information on suitable diesel fuel types for summer and winter periods.
Tractor Lubrication Chart
Diagram and table indicating lubrication points on the front driving axle.
Front Driving Axle Lubrication
Lubrication points and schedule for the front driving axle.
Three-Point Suspension Lubrication
Lubrication points for the tractor's three-point suspension system.
Front Three-Point Suspension Lubrication
Lubrication points for the front three-point suspension.
Tractor Overhaul Considerations
Considerations and service life estimations for tractor overhauls.
Adjustments
V-Belt Stretching
Procedure for adjusting the tension of the V-belt.
Cylinder Head Retightening
Instructions for retightening the engine cylinder head bolts.
Valve Play Adjustment
Steps for adjusting valve clearance on a cold engine.
Bleeding Tractor Brake System
General procedure for bleeding the tractor's brake system.
Bleeding Trailer Brake Valve
Specific steps for bleeding the main brake valve for trailer systems.
Bleeding Rear Wheel Brakes
Procedure for bleeding the brake system of the tractor's rear wheels.
Bleeding Front Driving Axle Brakes
Steps for bleeding the brake system of the front driving axle.
Bleeding Hydraulic Trailer Brakes
Procedure for bleeding hydraulic trailer brake systems.
Foot and Hand Brake Adjustments
Comprehensive checks and adjustments for both foot and hand brake systems.
Foot Brake Adjustment
Detailed steps for adjusting the tractor's foot brake.
Hand Brake Adjustment
Procedures for adjusting the tractor's hand brake mechanism.
Brake Pedal Free Travel Adjustment
How to set the correct free travel for the brake pedals.
Clutch Pedal Play Adjustment
Information on the non-adjustable clutch pedal play, set by the manufacturer.
Bleeding Clutch Hydraulic Circuit
Procedure for bleeding the clutch hydraulic circuit.
Engine Travel Clutch Adjustment
Notes on the travel clutch design requiring no adjustment during its service life.
Single-Axle Trailer Hitch Adjustment
How to adjust the hitch for single-axle trailers.
Digital Dashboard Calibration
Procedure for recalibrating the digital dashboard's travel speed display.
Essential Technical Parameters
Main Tractor Dimensions
Key physical dimensions of the tractor, varying with hitch and weights.
Tractor Engine Specifications
Detailed engine specifications for Proxima Plus models, including power, torque, and fuel consumption.
Permitted Front Axle Loading
Maximum permitted load capacities for the front axle based on travel speed and tyre size.
Permitted Rear Axle Loading
Maximum permitted load capacities for the rear axle based on travel speed and tyre size.
Vehicle Set Weight Limits
Maximum combined weight limits for tractor and attached mechanisms at different speeds.
Front Tyre Load Capacity
Table detailing front tyre load capacities and inflation pressures by speed and tyre size.
Rear Tyre Load Capacity
Table showing rear tyre load capacities and inflation pressures by speed and tyre size.
Permitted Wheel Combinations
Recommended front and rear tyre size combinations for tractors.
Tractor Power Specifications
Specifications for tractor engine power output, including run-in and operational values.
Forward Travel Speed (30 km/h)
Table of forward travel speeds for various gear and multiplier stages at 30 km/h.
Backward Travel Speed (30 km/h)
Table of backward travel speeds for various gear and multiplier stages at 30 km/h.
Forward Travel Speed (40 km/h)
Table of forward travel speeds for various gear and multiplier stages at 40 km/h.
Backward Travel Speed (40 km/h)
Table of backward travel speeds for various gear and multiplier stages at 40 km/h.
Rear Independent Output Shaft Speed
Speeds of the rear independent output shaft relative to engine speed.
Front Output Shaft Speed
Speeds of the front output shaft relative to engine speed.
Outer Contour and Track Diameters
Dimensions related to tractor contour and track wheeling.
Need help?
Do you have a question about the Proxima Plus 95 and is the answer not in the manual?
Questions and answers
