Cerberus™ PRO
OH720, OP720, HI720, HI722
Automatic fire detectors
A6V10202198_m_en_--
2018-06-15
For the automatically addressable detector bus C-NET
The ideal fire detector for every application
Signal processing with detection algorithms
Address automatically issued during commissioning
Communication via C-NET (addressed individually)
Building Technologies
Control Products and Systems
Advertisement
Related Manuals for Siemens S54310-F1-A1
Summarization of Contents
Properties of Automatic Fire Detectors
Detector Features and Capabilities
Details key features like environmental resistance, shock resistance, protected electronics, line separation, alarm indicators, and external indicator connections.
Environmental and Material Aspects
Covers environmentally friendly processing, use of reusable materials, and easy separation of electronic and synthetic components.
Use Cases for Fire Detectors
OH720 Multi-Sensor Detector Functionality
Explains the OH720's function using scattered light, its opto-electronic measuring chamber, heat sensor, and selectable detection behaviors.
OP720 Smoke Detector Functionality
Details the OP720 smoke detector's function based on scattered light, its opto-electronic chamber, and selectable detection behavior sets.
HI720 Heat Detector Functionality
Describes the HI720 heat detector's function for high requirements, its reliable response to temperature changes, and suitability for fluctuating environments.
HI722 Heat Detector Functionality
Outlines the HI722 heat detector's operation, measuring temperature and signaling danger when a maximum is exceeded, suitable for fluctuating temps.
Intended Use of Fire Detectors
Specifies that OH720, OP720, HI720, and HI722 detectors are for use on C-NET detector lines in FS720 or FC360 fire detection systems.
Detector Accessories
Detector Bases and Sounder Base
Covers detector bases DB721 and DB722, and sounder base DBS720, detailing their universal use and features.
Labeling and Sealing Accessories
Details designation plates (FDBZ291), detector base seal (RS720), and the base attachment BA720.
Mounting and Environmental Accessories
Covers detector locking device LP720, base attachment BA720, base attachment wet BA721, and designation plate DBZ1193A.
Detector Heating Unit and Protective Cage
Details the detector heating unit FDBH291 for critical conditions and the protective cage DBZ1194 for damage prevention.
Micro Terminal and Connection Terminal
Describes micro terminal DBZ1190-AA for up to 0.5 mm² cable and connection terminal DBZ1190-AB for up to 2.5 mm² cable.
Notes on Installation and Disposal
Installation Guidelines
Provides instructions for universal detector base mounting, cable entry options, screw terminals, and space for auxiliary terminals.
Disposal Instructions
Instructs to dispose of electronic devices according to European guidelines and local regulations, not as domestic garbage.
