Descriptions of All Connectors

ON/OFF

Power switch button

PWR

Connect with power adapter

Connect with Ethernet Cable to Switch Hub or PC

DEFAULT

Reset button

USB

Connect with USB cable to PC

LINE

Connect with phone cable

2.5 Connect Related Devices

1) Connect Router to LINE

Plug the provided RJ-11 phone cable into LINE port on the back panel of the router

and insert the other end into splitter or wall phone jack.

2) Connect Router to LAN

Plug RJ-45 Ethernet Cable into LAN port on the back panel of the router and insert

the other end of the Ethernet cable on your PC's Ethernet port or switch / hub.

3) Connect Router to Power Adapter

Plug Power Adapter to PWR port on the back panel of the router and the other end

to a power outlet.

4) Press ON/OFF button to start the router

5) If you connect your router via USB cable, plug the provided USB cable into USB

port on the back panel of the router and insert the other end of the USB cable to PC.

Warning! Only use the power adapter provided in the package, otherwise it may cause

hardware damage.
