Summarization of Contents
Basic Configuration and Name of Each Part
KE-2010/2020/2040
Details for specific machine models KE-2010, 2020, and 2040.
Standard Machine
Describes the standard configuration of the machine.
CE Machine
Describes the CE machine configuration.
KE-2030
Details for the KE-2030 model.
Standard Machine
Describes the standard configuration of the KE-2030.
CE Machine
Describes the CE machine configuration for KE-2030.
Detaching the Packing Materials from the Machine
Overall Machine Cover
Instructions for removing the overall machine cover packaging.
Safety Cover
Instructions for removing the safety cover packaging.
Transport Cover (only CE Machine)
Instructions for removing the transport cover packaging.
Pneumatic Units
Instructions for detaching air caps from pneumatic units.
Feeder Relay Cable 8 (For machines with fixed bank specification only)
Instructions for removing filament tapes from feeder relay cable.
Replacement Table Trolley
Instructions for detaching packaging from the replacement table trolley.
Overall Replacement Table Trolley
Detaching air cap cover from the replacement table trolley.
Feeder Relay Cable
Instructions for removing filament tapes from feeder relay cable.
Trolley Frame
Instructions for detaching P.P. band from trolley frame.
Adjusting the Transport Height and Leveling the Machine
KE-2010/2020/2040
Procedure for adjusting height and leveling for specific models.
KE-2030
Procedure for adjusting height and leveling for KE-2030.
X-Y Unit
Detaching the X-axis Frame Fixing Parts (For model 2030 only)
Instructions for detaching X-axis frame fixing parts.
Detaching the Head Fixing Parts
Instructions for detaching head fixing parts.
Head Unit
Detaching the Packing Materials
Instructions for detaching packing materials from the head unit.
Detaching the Head Unit Fixing Parts
Instructions for detaching the head unit fixing parts.
Detaching the MNLA Head Z-axis Fixing Parts
Detaching fixing parts for MNLA head Z-axis.
Detaching the FMLA Head Z-axis Fixing Parts
Detaching fixing parts for FMLA head Z-axis.
Board Transport Unit
Detaching the Packing Materials from the Transport Rail
Instructions for detaching packing materials from the transport rail.
Detaching the Packing Materials from the BU Table
Instructions for detaching packing materials from the BU table.
Center Station on the Y-axis Drive Side (For model 2030 only)
Instructions for removing packing material from Y-axis drive side.
Unpacking the Supply Parts
Instructions for unpacking backup pins and hand knobs.
Connecting the Power Cord
2010/2020/2040
Procedure for connecting power cord to specific models.
Standard Machine
Procedure for connecting power cord to standard machines.
CE Machine
Procedure for connecting power cord to CE machines.
Mounting the Accessories
Signal Light
Instructions for mounting the signal light accessory.
Vision Monitor
Instructions for mounting the vision monitor accessory.
Keyboard Bracket
Instructions for mounting the keyboard bracket accessory.
HOD (Handheld Operating Device)
Instructions for connecting the HOD accessory.
Hand Knob
Instructions for placing the hand knob accessory.
Feed Relay Cable
Instructions for connecting the feed relay cable.
Chip Box
Instructions for installing the chip box.
KE-2010/2020/2040
Instructions for installing the chip box for specific models.
KE-2030
Instructions for installing the chip box for KE-2030.
Interface with External Equipment
KE-2020/2040
Describes interfaces for external equipment on specific models.
KE-2010/2030
Describes interfaces for external equipment on KE-2010/2030.
Connecting the Matrix Tray Changer (MTC)
Interface Panel
Instructions for connecting MTC to the interface panel.
TR-4SN
Instructions for mounting the TR-4SN unit.
TR-6SN and TR-6DN
Instructions for mounting TR-6SN and TR-6DN units.
TR-5SN and TR-5DN
Instructions for mounting TR-5SN and TR-5DN units.
Adjusting the Height of the Overall Feeder Exchange Trolley (Optional)
Caster Plate Mounting Position
Instructions for adjusting caster plate mounting position for height.
Adding the Trolley Spacers (For height adjustment)
Instructions for adding trolley spacers for height adjustment.
Adjusting the Bank Stopper Mounting Position
Instructions for adjusting bank stopper mounting position.
Adjusting the Bank Valve Position
Instructions for adjusting the bank valve position.
