TOWER 10 AM, TOWER 12 AM [GRADE 3]
English Anti-Masking PIR and Dual technology (PIR/MW) Mirror Detectors -
Installation instructions
Detectores de espejo (PIR/MW) Doble Tecnología y Anti-Masking
Español
Detectores de Espelho PIR e Dupla Tecnologia (PIR/MW) Anti-
Portuguese
Mascara. Instruções de Instalação
ENGLISH
1. INTRODUCTION
The TOWER 10 AM PIR and TOWER 12 AM Dual Technology are
professional vandal resistance Anti-Masking detectors designed for
large commercial and industrial applications providing wide coverage
with superior resistance to harsh environment, employing several
revolutionary patented technologies
50131 Grade 3.
Features:
• V-slot® recessed small window technology (patent pending) for
extreme mechanical robustness and protection from false alarms
(patent pending).
• "Obsidian Black Mirrors"™ and "Elliptic / Parabolic Mirror"
technology providing over 15,000 LUX resistance to white light and
multiple-solid curtain pattern with 50% better sensitivity than
comparable mirror optics (several patents pending).
• Adaptive Active Infra-Red Anti-Masking technology providing the
most advanced reliable protection against intentional masking
attempts (patent pending).
• Optional interchangeable Long-Range Curtain mirror providing 35m
x 2.5m (115ft x 8.2ft) coverage for TOWER-10 and 25 x 2m (82 x
6.5ft) coverage for TOWER-12.
• Installer friendly features:
Built-in selectable E.O.L. resistors for alarm, trouble and tamper outputs.
Plug-in terminals attached to base for easy pre-wiring.
Unique sliding closing mechanism with captive screw.
Extended mounting height 1.5 - 4m (5 - 13 ft.).
Low supply voltage indication.
Remote controlled walk-test input.
Optional mounting brackets.
Selectable range adapted to the protected area size by use of a
Range Selector (TOWER 12 AM).
• Microprocessor controlled, digital TMR signal processing with dual-
slope digital temperature compensation.
• Front and Back tamper.
• True "Creep zone" down looking optics.
• Pet immunity (18Kg/40lb) using a special "pet mask".
• Built-in auto diagnostic for both PIR and microwave detectors.

2. SPECIFICATIONS

OPTICAL
Wide Angle
TOWER 10 & 12
coverage
25mx30m / 90º
Far Field Of View (FOV) 11 curtains
Medium FOV 6 curtains
Event counter settings
Mounting:
Method: Surface, corner or at 45º to wall.
Height: 1.5 - 4m (5-13 ft.) without bracket.
Vertical adjustment: Angled base surface provides three tilt
adjustments according to mounting height and coverage range.
ELECTRICAL
Sensors type:
PIR: dual element low noise pyroelectric sensor.
MW: X-Band Doppler module.
For UK - 10.687 GHz, for EU / USA – 10.525 GHz. For
German/Czech 9.35 MHz
Supply voltage: 8 – 16 VDC.
Low voltage detection: If input voltage is below 7.5 VDC.
Supply current:
Standby @ 12 VDC: 12mA (TOWER 10 AM). 15 mA (TOWER 12).
Maximum: 14mA (TOWER 10 AM). 18 mA (TOWER 12).
D-300909
.
Both detectors comply with EN
Mirror Types (see Fig. 2)
Long Range Curtain
TOWER 10 TOWER 12
35m / 5º 25m / 5º
1 curtain
1 curtain
1 or 2 LR
EN: Yellow, red & green LEDs
SP: LEDs amarillo, rojo y verde
PT: LEDs amarelo, vermelho e verde
Figure 1 - TOWER 10 AM / TOWER 12 AM
Alarm period: 2 to 3 sec.
Masking detection delay: 30 sec.
Remote LED enable input (TST): High impedance input. Affects
LEDs operation only if internal LEDs selector is set to OFF.
Outputs:
Alarm output: Solid State Relay. NC, 100 mA / 30 V, 35 ohm
maximum internal resistance. "Open" for 2 – 3 sec. in case of
alarm, masking event or complete power failure.
Trouble output: Solid State Relay. NC, 100 mA / 30 VDC, 35 ohm
maximum internal resistance. "Open" in case of auto-diagnostic
failure, Anti-Mask event, low voltage or complete power failure.
Tamper output: NC switch, 50mA / 30 VDC. "Open" by opening
detector's cover or removing it from mounting surface.
Built-in End Of Line resistors circuit: Selectable serial resistors for
each of the three outputs. Resistors values: 0 Ohm (Factory default),
1K, 2.2K, 4.7K, 5.6K Ohm (see figure 5).
LED indications:
Event / status
TOWER 12
Low voltage
Warm-up Yellow + Red + Green
(60sec.) flashing alternately
Self-test failure Yellow + Red flashing simultaneously
AM detection
ALARM
PIR detection Green flashing
MW detection Green ON
Warm-up time: 60 sec.
ENVIRONMENTAL
Operating Temperature: –20°C to 55°C (-4°F to 131°F).
Storage Temperature: –20°C to 60°C (–4°F to 140°F)
RFI Protection: Greater than 20 V/m (up to 2 GHz).
Housing: IP41 and IK04 .
Dimensions: 160x77x47mm (6-5/16 x 3 x 1-13/16 in.)
Optional ACCESSORIES:
BR-1: Surface mounted swivel bracket, adjustable 30° down and 45°
left/45° right.
BR-2: BR-1 with a corner adapter
BR-3: BR-1 with a ceiling adapter
CURTAIN-10/12: Interchangeable long range 35m/5° curtain mirror
PET-10/12: Pet mask provides 18Kg/40Lb pet immune for wide angle
mirror only.
Standards:
Designed to comply with EN50131-1 Grade 3 / Class II,
EN50131-2-2, EN50131-2-4, EN300440, EN301489, EN60950.
Belgium standard TO14.
Sweden standard: SSF 1014.
3. INSTALLATION
3.1 General Guidance
(See figure 3)

3.2 Installation Procedure

(See figure 4 & 5).
3.3 Jumpers setting
3.4 Long Range Mirror mounting
Optional for TOWER-10 AM - See figure 6. For long range mirror, the
COUNT (counter) jumper should be set to "LR" position (see fig. 5).
3.5 Pet Mask Mounting (optional)
For pet immunity (up to 18Kg/40lb), a special "pet mask" model PET
10/12 should be mounted on the mirror (see figure 6, step 4a).
Indication
TOWER 10 AM
Red flashing
Yellow + Red
flashing alternately
Yellow ON
Red ON
---
---
(See figure 5)
