Summarization of Contents
Safety Instructions
High Temperatures and Microwave Ovens
Avoid high temperatures and microwave ovens due to explosion hazard of the lithium battery.
Explosion-Hazardous Areas
Observe regulations for explosive areas; do not use if housing metallization is damaged.
1 Description
Logger Features and Versatility
Easy-to-use, versatile logger for temperature and absolute pressure with interchangeable adapters.
PC Connectivity and Software
Connect logger to PC via RS 232 for programming and data readout using WINLOG 2000 software.
Use in Hazardous Areas
Type 814-Ex for combustible media in potentially explosive atmospheres; requires integration into pressure-check.
2 Extent of the Delivery
Standard Package Contents
Includes logger, sensor cable, sensor head, and adapters for tube, glass, and flange connections.
Optional Accessories
Optional items include RS 232 cable, interface adapter, WINLOG 2000 software, and software manual.
3 Installation
3.1 Connecting Sensor Head and Adaptor
Plug Lemosa connector of sensor cable into sensor head; screw in desired adaptor for a firm fit.
3.2 Choice of the Site
Select a suitable site, hang by eye, avoid electric fields and water. Protect extension cable from damage.
3.3 Programming and Readout of the Logger
Use WINLOG 2000 software to program and read data. Connect logger to PC via RS 232 cable.
4 Operation Indicators
Battery Life and Measurement Settings
Measuring interval and ambient temperature influence battery life; example values provided for 25°C.
Pressure and Temperature Display Details
Triangle indicates pressure (above '1') or temperature (above '2'); '°C' shown for temperature.
6 Ex-Accreditation
6.1 Use in Ex-area
Logger EBI-2PT-814-Ex approved for Zone 1 hazardous areas. Conditions: matching serial numbers and sensor must not be disconnected.
7 Appendix
I What to do, when?
Troubleshooting guide for measurement range issues, sensor defects, and connection problems.
II Accessories
Lists available accessories, including the EBI case (Samsonite case).
III Technical Data
Key technical specifications: storage/operating temp, sensor, resolution, measuring intervals, and battery life.
