1. Intel Server Family Overview
1.1 Configuration Overview
Describes the Intel Server System S9200WK product family structure and core components.
1.1.1 Processor Support
Details the supported Intel Xeon Platinum 9200 processors and their capabilities.
1.1.2 Memory Support
Outlines memory types, speeds, capacities, and error correction features.
1.2 Additional Information and Software
Lists resources for technical specifications, guides, and software downloads.
1.3 Intel® Server System S9200WK Feature Overview
Provides visual overviews of system configurations and compute module layouts.
1.4 Intel® Compute Module S9200WK Product Family Feature Overview
Details the specific features and external interfaces of 1U compute modules.
2. Server System Configuration
2.1 Intel® Server System S9200WK Product Family Compute Module Options
Lists available compute module options with their specifications and included parts.
2.2 Intel® Server Chassis FC2000 Product Family Options
Details available chassis options, including specifications and included components.
3. Accessory Options
3.1 Rack and Cabinet Mount Kits
Details the fixed rail kit option for secure server rack mounting.
3.2 Miscellaneous Accessory Options
Covers I/O breakout cables and Ethernet management port modules.
3.3 Other Accessory Options
Includes compute module blanks, VROC keys, RMM4 Lite keys, and fabric interface adapters.
4. Spare and Replacement Parts (FRUs)
Riser Cards
Riser cards for 1U/2U compute modules supporting PCIe and M.2 devices.
Cooling Components
Spare heat sinks, liquid cooling loops, and M.2 heat sinks for thermal management.
Power Supplies and Fans
Spare power supply units (1600W, 2100W) and fan assemblies (60mm, 80mm).
Chassis and Module Components
Spare chassis plumbing connections, fan assemblies, and power distribution boards.
Internal Rail and DIMM Retention Kits
Spare internal rail kits for 1U modules and DIMM retention clips for liquid cooling.
