as flown mid-bass elements (crossed in at 60Hz and out at 160Hz) to augment floor-
stacked WSXs working as low subs below 60Hz. Refer to
Power amplifier monitoring at real-world gigs have shown that half of the total
system power is demanded between 60Hz & 160Hz during heavy rock and dance
music.
W8CS' flown in columns with W8Cs
Flying W8CS' in columns between W8C columns keeps clusters shorter whilst
MARTIN AUDIO - APPLICATIONS GUIDE, WAVEFRONT COMPACT SERIES
ENGLISH ONLY
15
15
20 20
20
20 20 20
15 15
Again, coverage would be 145º Horizontal x 70º Vertical.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
Section 2.4.
15
15
15
20 20
20 20
15
15 15
GUIDES
15
20 20
20 20
15
