Choose metric or imperial units using the Units box on the Venue page.
Click on the button adjacent to the units that you would like to use.
Note: if you enter dimensions in one unit system and then click on the button of the
other system all dimensions will be converted, i.e. 1m will become 3.28ft.
PLEASE NOTE!
ViewPoint
resolution drawing programme.
It indicates optimum line array curvature based on simple audience dimensions that
may be gathered from basic venue drawings or from a quick on-site survey.
For best results, planes should be used as follows:
Plane 1 is used to simulate the main floor area from the stage to a rear bleacher or
boundary.
Plane 2 is used to simulate any audience continuation behind Plane 1 (e.g. a rear
bleacher) from the end of the main floor to furthest and highest seat below Plane 3.
Plane 3 is used to simulate the furthest/highest audience area.
Example:
W8L
W8LC
W8LM
Entering venue data
tm
is designed as a line array design aid. It does not claim to be a high
Plane 1, plane 2 and plane 3 decisions
