Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE Application Manual page 80

< >
CONTENTS
Maximum SPL:
Impedance:
Connectors:
Cabinet construction:
Cabinet finish:
Protective grille:
Grille finish:
Dimensions (inc wheels):
Flown weight:
Before rigging, note colour coding!
MARTIN AUDIO - APPLICATIONS GUIDE, WAVEFRONT COMPACT SERIES
ENGLISH ONLY
132dB continuous, 138dB peak
8 ohms nominal
2 x Neutrik NL8
Birch Ply
Slate textured paint
Perforated steel
Grey paint
(W) 562mm x (H) 799mm x (D) 925mm
(W) 22.1ins x (H) 31.5ins x (D) 36.4ins
61kg (134lb). Lid 4kg (9lb) extra
All material © 2007. Martin Audio Ltd. Subject to change without notice.
W8C has 2 black points per side
W8CS has 1 black point per side
W8CT has 2 orange points per side
W8CM has 1 orange point per side
