Adjusting the array height slightly on the Venue page will often position the system
on a suitable hole or narrow the gap between the required angle and the angle given
by the nearest hole. Flip between Venue and Array pages to set and recheck.
(If the required lifting point is too far back, make sure that the lifting bar is in the rear
position and that the cabinet is mounted at the front of the grid before trying an
alternative height. Similarly, if the required lifting point is too far forward, make sure
that the lifting bar is in the front position and the cabinet is mounted at the rear of the
grid before trying an alternative height)
Two Point Lift
This places a pick point at each end of the bar.
