Rated power:
Sensitivity:
Maximum SPL:
Impedance:
Coverage (-6dB):
Crossover:
Connectors:
Cabinet construction:
Cabinet finish:
Protective grille:
Grille finish:
Dimensions (incl wheels):
Weight:
MARTIN AUDIO - APPLICATIONS GUIDE, WAVEFRONT COMPACT SERIES
ENGLISH ONLY
Low-mid 400W AES, 1600Wpk
High-mid (active/passive) 150WAES, 600Wpk
High (active) 60W AES, 240Wpk
Low-mid 106dB/W
High-mid 108dB/W
High 107dB/W
129dB continuous, 135dB peak
Low-mid 8 ohms nominal
High-mid 16 ohms nominal
High 16 ohms nominal
55º horizontal, 30º vertical
750Hz, 3.5kHz
2 x Neutrik NL8, 2 x EP8
Birch Ply
Slate textured paint
Perforated steel
Grey paint
(W) 562mm x (H) 1066mm x (D) 925mm
(W) 22.1ins x (H) 42.0ins x (D) 36.5ins
90kg (198lbs)
