Shinko BCS2 Communication Instruction Manual

COMMUNICATION INSTRUCTION MANUAL
This manual contains instructions for communication functions of the BCD2, BCR2, BCS2.
Serial communication and Console communication cannot be used together.
When performing Serial communication, remove the tool cable (CMD-001) from the USB port of the PC and
console connector of the BCD2, BCR2, BCS2.
When performing Console communication, it is not required to remove the Serial communication cables.
However, do not send a command from the master side.

1. System Configuration

1.1 When Using USB Communication Cable CMC-001-1 (sold separately)
Host computer
1.2 When U
sing Communication Converter
Host computer
USB communication cable
CMC-001-1 (sold separately)
(Fig. 1.1-1)
Communication converter
IF-400 (sold separately)
RS-232C RS-485
(Fig. 1.2-1)
BCD2, BCR2, BCS2 (C5W, C5)
BCS2
No. 0 No. 1
IF-400 (sold separately)
BCS2
No. 0 No. 1
1
No. BCx2CE5 2018.02
No. 30
No. 30
