INSTRUCTION MANUAL
Micro-computer based Temperature Indicating Controller
To prevent accidents arising from the use of this controller, please ensure the operator using it receives
this manual.
Warning
Turn the power supply to the instrument OFF before wiring or checking.
Working or touching the terminal with the power switched ON may result in Electric Shock,
which can cause severe injury or death.
1. Model names
1.1 FCL-130
F C L - 1 3 0 - / E
Temperature alarm 0
Control output
Input
Option
Range
Temperature alarm action is not equipped for the FCL-130 type.
There are 2 input types for the FCL-130; TC (thermocouple) multi-range input and TC K type only.
The options applicable to the FCL-130 are [TC] and [BK].
When ordering:
Choose a type from the table above with alphanumeric characters.
Enter a rated scale (only for the TC K type) and supply voltage using a comma (,).
1.2 FCL-13A
F C L - 1 3 A - /
Temperature alarm A
Control output
Input
Option
Range
There are 2 input types for the FCL-13A; Multi-range input and TC K type only.
,
R
S
A
E
TC
BK
0 to 400
0.0 to 400.0
0 to 750
0.0 to 750.0
,
R
S
A
M
E
C5
W( 5A)
W(10A)
W(20A)
W(50A)
SM
TC
BK
0 to 400
0.0 to 400.0
0 to 750
0.0 to 750.0
FCL-100 (W48 x H24 x D98.5mm)
No alarm action
Relay contact
Non-contact voltage (for SSR drive)
Current (4 to 20mAdc)
TC multi-range input, or TC K type only
Terminal cover
Color, black
The range designation is required for TC
(thermocouple) K type only.
(Changeable by the key operation.)
FCL-13A (W48 x H24 x D98.5mm)
Alarm action applied
Relay contact
Non-contact voltage (for SSR drive)
Current (4 to 20mAdc)
Multi-range input
TC K type only
Serial communication
Heater burnout
alarm
Setting value memory (external selection)
Terminal cover
Color, black
The range designation is required for TC
(thermocouple) K type only.
(Changeable by the key operation.)
FCL-100
No.FCL11E3 2000.11
RS-485
Rated current: 5A
Rated current: 10A
Rated current: 20A
Rated current: 50A
