Shinko BCS3 Series Instruction Manual

Digital temperature indicating controller

Advertisement

INSTRUCTION MANUAL
Thank you for purchasing our Digital Temperature Indicating Controller BCS3.
This manual contains instructions for the mounting, functions, operations and notes when operating the BCS3.
To ensure safe and correct use, thoroughly read and understand this manual before using this unit. To prevent
accidents arising from the misuse of this unit, please ensure the operator receives this manual.
Safety Precautions
The safety precautions are classified into 2 categories: "Warning" and "Caution".
Warning
: Procedures which may lead to dangerous conditions and cause death or serious injury, if not
carried out properly.
Caution
: Procedures which may lead to dangerous conditions and cause superficial to medium injury or
physical damage or may degrade or damage the product, if not carried out properly.
Warning
• To prevent an electrical shock or fire, only Shinko or other qualified service personnel may handle the inner
assembly.
• To prevent an electrical shock, fire or damage to the instrument, parts replacement may only be
undertaken by Shinko or other qualified service personnel.
Safety Precautions
• To ensure safe and correct use, thoroughly read and understand this manual before using this instrument.
• This instrument is intended to be used for industrial machinery, machine tools and measuring equipment.
Verify correct usage after purpose-of-use consultation with our agency or main office. (Never use this
instrument for medical purposes with which human lives are involved.)
• External protection devices such as protection equipment against excessive temperature rise, etc. must
be installed, as malfunction of this product could result in serious damage to the system or injury to
personnel. Proper periodic maintenance is also required.
• This instrument must be used under the conditions and environment described in this manual. Shinko
Technos Co., Ltd. does not accept liability for any injury, loss of life or damage occurring due to the
instrument being used under conditions not otherwise stated in this manual.
Caution with Respect to Export Trade Control Ordinance
To avoid this instrument from being used as a component in, or as being utilized in the manufacture of weapons
of mass destruction (i.e. military applications, military equipment, etc.), please investigate the end users and the
final use of this instrument. In the case of resale, ensure that this instrument is not illegally exported.
1. Model
1.1 Model
Series
Control output
(OUT)
Power supply
voltage
Input
Event output
(SA option)
Drip-proof/
Dust-proof
(IP option)
(Be sure to read these precautions before using our products.)
BCS3
Relay contact
Non-contact voltage
100 to 240 V AC
Thermocouple (K, J),
RTD (Pt100) Multi-input
Thermocouple (R, S, T)
Multi-input
No alarm output
2-points alarm output
Unavailable
Available
Digital Temperature Indicating Controller
BCS3
R
-
0
0
BCS3
R
S
0
1
和文は裏面をご覧下さい。
No.BCS31JE1 2024.08
M00
-
0
0
M00
M01
0
2
0
1
BCS3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCS3 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Shinko BCS3 Series

  • Page 1 Warning • To prevent an electrical shock or fire, only Shinko or other qualified service personnel may handle the inner assembly. • To prevent an electrical shock, fire or damage to the instrument, parts replacement may only be undertaken by Shinko or other qualified service personnel.
  • Page 2: Name And Functions

    1.2 How to Read the Model Label Model labels are attached to the right side of the case (Fig.1.2-1) and at the left side of the inner assembly (Fig.1.2-2). (E.g.) Control output (OUT): Relay contact output Supply voltage: 100 to 240 V AC Input: Thermocouple (K, J), RTD (Pt100) Multi-input Event output:...
  • Page 3 3.2 External Dimensions (Scale: mm) Mounting frame (*2) Terminal cover (sold separately) Gasket A (*1) (*1) Included when Drip-proof/Dust-proof (IP option) is ordered. (*2) Screws are included when Drip-proof/ Dust-proof (IP option) is ordered. (*3) When Terminal cover (sold separately) 66.3(*3) is used.
  • Page 4 4. Wiring Warning Turn the power supply to the instrument OFF before wiring or checking. Working on or touching the terminal with the power switched on may result in severe injury or death due to electrical shock. Caution • The terminal block of this instrument is designed to be wired from the left side. The lead wire must be inserted from the left side of the terminal, and fastened with the terminal screw.
  • Page 5 5. Operation Flowchart POWER ON PV/SV Display Mode Control output OFF Output MV indication (Approx. 3 sec.) function (Decimal point on SV Display flashes.) (Approx. 3 sec.) (Approx. 3 sec.) (Approx. 3 sec.) [Main Setting Mode] [Sub Setting Mode] [Function Setting Mode] [Setup Mode] SV (desired value) AT/Auto-reset...
  • Page 6 Indication after the power is turned on After the power is turned ON, the PV Display indicates the input type characters and temperature unit, and the SV Display indicates the input range high limit value for approximately 3 seconds. See (Table 5-1). (Table 5-1) Input Setting Range...
  • Page 7: Operation

    Characters Used in this Manual: Indication Number, Indication Alphabet Indication Alphabet 6. Operation After the unit is mounted to the control panel and wiring is completed, operate the unit following the procedure below. (1) Turn the power supply to the BCS3 ON. (2) Input each set value.
  • Page 8: Specifications

    IP65 for the front panel, IP20 for the rear case, IP00 for the terminals proof (IP option) If you have any inquiries, please consult our agency or the vendor where you purchased the unit. SHINKO TECHNOS CO., LTD. OVERSEAS DIVISION Head Office:...
