Summarization of Contents
FEATURES
TRIPLE OUTPUT
Operates as three separate power supplies, each completely isolated.
UNIQUE TRACKING FEATURE
Allows 'B' supply voltage to track 'A' supply voltage for synchronized operation.
CONSTANT VOLTAGE OR CONSTANT CURRENT
Provides regulated DC voltage or DC current output with automatic crossover.
OVERLOAD PROTECTION
Adjustable current limiting protects unit and circuit from excessive current.
SPECIFICATIONS
"A" AND "B" SUPPLIES
Details specifications for the primary adjustable voltage and current outputs.
"Third" SUPPLY
Specifications for the fixed 4-6.5V auxiliary output with 5A capacity.
CONTROLS AND INDICATORS
GENERAL CONTROLS AND INDICATORS
Describes the main power, mode selection, and display controls.
"A" SUPPLY CONTROLS AND INDICATORS
Details controls and indicators for the primary 'A' output.
"B" SUPPLY CONTROLS AND INDICATORS
Details controls and indicators for the primary 'B' output.
REAR PANEL CONTROLS
Identifies controls and connections located on the rear of the unit.
OPERATING INSTRUCTIONS
Hook-up
Procedure for connecting the power supply to the device under test.
Typical Constant Voltage Operation
Step-by-step guide to operating the supply in constant voltage mode.
Setting Current Limit
Instructions for configuring the maximum output current protection.
SERIES TRACKING OPERATION
Guide to operating 'A' and 'B' supplies in series for double voltage.
PARALLEL TRACKING OPERATION
Guide to operating 'A' and 'B' supplies in parallel for double current.
APPLICATIONS
GENERAL
Overview of the power supply's versatility and broad applicability.
ELECTRONICS SERVICING
Use of the power supply for troubleshooting and repairing electronic equipment.
SPLIT SUPPLY
Configuring the unit to provide multiple voltage rails for circuits.
Two Identical Positive Voltages With a Common Negative
Hook-up for providing dual positive voltages with a shared negative reference.
MAINTENANCE
FUSE REPLACEMENT
Procedure for replacing blown fuses to restore unit operation.
LINE VOLTAGE CONVERSION, INTERNATIONAL UNITS
Instructions for switching between 120V and 220/240V operation.
"A" SUPPLY AND "A" METERING ADJUSTMENTS
Calibration steps for the 'A' supply voltage and current metering.
"B" SERIES TRACKING ADJUSTMENT
Procedure to calibrate the voltage tracking between 'A' and 'B' supplies.
