Summarization of Contents
About this guide
Introduction
Introduction and overview about this manual.
Safety notes conventions
Defines risk levels and conventions for safety notes.
Text formats and conventions
Explains formatting conventions for procedures and web links.
Safety
Safety Notes
General safety notes for operating the Axiocam 503.
Limitation of liability
ZEISS liability limitations related to operation and safety.
Warranty
Warranty conditions and ZEISS obligations regarding safety.
Technical Data
Axiocam 503 color/mono
Detailed specifications for Axiocam 503 color and mono.
Binning Mode and Frame Rate
Table detailing binning modes and their corresponding frame rates.
Live Frame Rates
Maximum frame rates for Axiocam 503 color and mono at optimum settings.
Spectral Sensitivity
Graphs showing spectral sensitivity for color and mono models.
Connecting the Camera
Camera Overview
Diagram and description of camera connections and ports.
Building in the interface card
Instructions for installing the PCI express interface card into a PC.
Mounting the camera on the microsope
Guidance on mounting the camera using C-mount adapters.
Connecting the camera to the PC
Steps for connecting the camera to the PC via USB cables.
Connecting the trigger cable
Instructions for connecting the optional trigger cable.
Function indicator
Explanation of the status LED colors and their meanings.
Installing Software and drivers
Installing software and drivers
Procedure for installing ZEISS software and camera drivers.
Maintenance
Optical System
Guidance on protecting the camera's internal optical components.
Cleaning the infrared filter or protective glass
Instructions for cleaning the IR filter or protective glass.
