ProStart CT-3200 Installation Manual

C H A N N E L
Introduction ...................................................2
Included in the Package ...............................2
Installation Tools:..........................................2
Before You Get Started...........................2
Harness Description .....................................3
6-Pin Main Ignition Harness.....................3
5-Pin Secondary Harness........................4
12-Pin Accessories Harness....................5
Flashing the Hood Pin ..................................7
The Programming Assistance Button (a.k.a.
PAB.) ............................................................8
Before Programming a Transmitter ..............8
How to Program the Transmitter. .................8
How to Enter Programming Options Mode...8
Programming Options...................................9
Auto Tach Programming Procedure .............9
Multi-Speed Tach Programming.................10
Testing ........................................................10
Closing Up ..................................................11
Please note:
Button
Button
Buttons
The LED is NOT included in this model.
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper
installation of the product, be that either damage to the vehicle itself or to the Unit. This Unit must
be installed by a certified technician using all safety devices supplied. Please note that this guide
has been written for properly trained Autostart technicians, a certain level of skill and knowledge is
therefore assumed. Please review the Installation Guide carefully before beginning any work.
Warning
This Unit is designed for vehicles with an automatic Transmission only. Before installing the
Unit, test that the vehicle does not start when the gear select lever is in the "Drive" position. If it
starts in gear, install a manual-transmission car starter instead.
DOC.1.50
Downloaded from www.Manualslib.com
A U T O M A T I C
R E M O T E
Installation Guide
Ι
is for the functions.
LOCK/UNLOCK
ΙΙ
is for the functions.
START/STOP
Ι ΙΙ
& (together) is for the
CA -
manuals search engine
T R A N S M I S S I O N
S T A R T E R
CT-3200
