Operation
LTS 15, LTS 17, ProLTS 17 and ProLTS 19
Airless Sprayers
-
For portable spray applications of architectural paints and coatings. For professional use only-
Models 257060, 257065, 24N906, 24N808
3000 psi (21 MPa, 207 bar) Maximum Working Pressure
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this
manual. Save these instructions.
See page 2 for model and series information including
dispense rate, recommended hose length, guns, and
maximum working pressure.
Related Manual:
313036 - Repair
ti11304a
M
LTS 15
AGNUM
Model: 257060
LTS 15 & LTS 17 Models ONLY: Use water-based or min-
eral spirit-type materials only. Do not use materials having
flash points lower than 70° F (21° C). This includes, but is
not limited to, acetone, xylene, toluene, or naptha. For more
information about your material, request MSDS from distrib-
utor or retailer.
ti11305a
M
LTS 17
AGNUM
Model: 257065
ti9369b
M
P
LTS 17
AGNUM
RO
Model: 24N906
313034H
EN
ti9368b
M
P
LTS 19
AGNUM
RO
Model: 24N808
Advertisement
Table of Contents
Related Manuals for Graco MAGNUM PROLTS 17 24N906
Summarization of Contents
Warnings
Grounding Requirements
Details proper grounding procedures to prevent electric shock.
Fire and Explosion Hazards
Warnings about flammable materials, ignition sources, and static electricity.
Skin Injection Hazard
Risks associated with high-pressure spray injecting fluid into the body.
Equipment Misuse Hazards
Dangers of operating the sprayer while fatigued, under influence, or exceeding limits.
Electric Shock Hazard
Precautions related to electrical grounding, connections, and water exposure.
Pressurized Aluminum Parts Hazard
Risks from incompatible fluids reacting with aluminum components.
Burn Hazard
Warning about hot surfaces and fluids causing burns.
Moving Parts Hazard
Risks of pinching or amputation from moving machine parts.
Toxic Fluid or Fumes Hazard
Dangers of inhaling or contacting toxic fluids and fumes.
Personal Protective Equipment
Recommendations for protective gear to prevent injury.
Installation
Grounding and Electric Requirements
Details grounding requirements, outlets, and extension cords for safe operation.
Thermal Overload Protection
Explains the motor's thermal overload protection and restart procedure.
Operation
Trigger Lock Usage
Instructions on how to engage the trigger lock to prevent accidental firing.
Pressure Relief Procedure
Steps to safely relieve pressure before servicing or cleaning the sprayer.
Pressure Control Knob Settings
Explains the different settings of the pressure control knob.
Setup
Priming and Flushing Procedures
Guides on priming the sprayer and flushing fluids for first use or material changes.
Material Handling: Oil vs. Water-based
Instructions for flushing the system when switching between oil and water-based materials.
Install Tip and Guard on Gun
Step-by-step instructions for installing the spray tip and guard assembly.
Spraying Techniques
Covers spray pattern adjustments, pressure settings, and tip wear.
Unclogging the Spray Tip
Procedure for clearing obstructions from the spray tip.
Spray Tip Selection Guide
Information on choosing the correct tip hole size and fan width for different coatings.
Understanding Tip Numbers
Explains how to interpret the spray tip number for hole size and fan width.
Getting Started With Basic Techniques
Aiming and Triggering the Gun
Basic techniques for aiming the gun and pulling the trigger for an even spray pattern.
Shutdown and Cleaning
Pail Flushing
Steps for flushing the sprayer after use with oil-based or water-based coatings.
Power Flush Procedure
Instructions for performing a faster flush using water-based coatings.
Cleaning Spray Gun Components
Guide for cleaning the InstaClean fluid filter and the spray gun.
Storage
Short Term and Long Term Storage
Procedures for storing the sprayer for short or extended periods.
Stowing the Sprayer
Instructions on how to prepare the sprayer for storage.
Maintenance and Service
General Sprayer Care
Tips on maintaining the sprayer, including cleaning and vent holes.
Pump Packings and Hoses
Information on pump packing wear, replacement, and paint hose inspection.
Tips for Sprayer Use
Advice on cleaning and replacing spray tips for optimal performance.
