Graphic Display

Shows the EQ in a graphic form. The active section (Early or Late) is in the forefront.

Early/Late Selectors

These buttons select which EQ section is currently being edited. 'Early' includes
reflections, direct echo outputs and room patterns. 'Late' includes the reverb tail.

EQ Type Selector

Allows any of six types of EQ to be applied to the active section. Those types are:
• Single-pole lowpass (6db / Octave)
• Single-pole highpass (6db / Octave)
• Double-pole lowpass (12db /Octave)
• Double-pole highpass (12db / Octave)
• Bandpass
• Notch

Level Control

Overall output level of the active section. These may be edited by holding the
mouse down and moving up and down over the knob. Alternatively, the value
field may be directly edited.

EQ Parameters

Frequency, shelf and bandwidth parameters of the active section. To edit these,
click and hold on the knob, then move the mouse up or down. Alternatively, the
value field may be directly edited. The bandwidth knob is only available when the
filter type is Bandpass or Notch.
