Inverse - Lexicon REFLEX - REV User Manual

HF Cut Diffusion
APM Parameter
Setting Name
1 Size
2 Predelay
3 Effects Level
4 – –
5 High Frequency Cutoff
6 Slope
7 Predelay Feedback
8 Diffusion
9 – –
10 – –
Pdly Fbk
Inverse Room
Size
Predelay
Slope
Display Range Actual Range
1 to 32 1-32 meters
1 to 128 0-246ms
1 to 128 0-100%
– – – –
1 to 16 321Hz-13.8kHz
1 to 32 1-32 (arbitrary units)
-128 to +128 -99 to +99%
1 to 128 0-100 (arbitrary units)
– – – –
– – – –
27
Inverse Reverb is similar to gated reverb,
except that the reverberation envelope is
sharply tilted to provide a long rising attack
followed by a sharp cutoff.
Effects
This algorithm is an excellent choice for
Level
percussion and the controls allow you to set
up anything from a subtle thickening or en-
hancement to a solid wall of reverb. Size
adjusts the perceived length of the inverse
effect. As this parameter changes both time
and density, it subtly affects the timbre.
This algorithm was used to create Preset
7.

Inverse

A6
