The last row of each algorithm's edit matrix is the Patch row. This row provides
parameters for creating as many as ten patches in each effect. Each row position
(Patch 0-9) has three controls available: Src, Dst, and Values. Press Load/
to cycle among these selections.
Src
Use ADJUST to select any of the sources listed below.
Dst
Use ADJUST to select any effect parameter except those on the Patch row.
Values
Use ADJUST to assign Destination values to specific Source values. These
assignments are made in pairs, each with a value for the Source and a value for
the Destination. For example, the default is two pairs mapped as follows:
minimum Source value (0) = minimum Destination value
maximum Source value (127) = maximum Destination value
This gives you a linear relationship between the parameter and the controller.
Inverse control is accomplished easily by reversing these settings. As many as
eight pairs of Destination/ Source values can be assigned here, providing an
exciting new level of dynamic control.
See Chapter 2 for a complete description of the Patching System.
Internal
LFO
Sine
Cosine
Square
Sawtooth
Pulse
Triangle
Env L
Env R
AR Env
Latch
Sw 1
Sw 2
Sw 1 & 2
Mono Lvl
Left Lvl
Right Lvl
Footpedal
Foot Sw 1
Foot Sw 2
ADJUST
Tempo
On
Off
P Bend
A Touch
Velocity
Last Note
Low Note
High Note
Clk Comnds
PCM 81 Patch Sources
(PCM 81 interprets 000 as Bank Select)
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
016
017
018
019
020
...
031
(PCM 81 interprets 032 as Bank Select)
033
...
063
MIDI
064
065
066
067
068
069
MIDI Controller Numbers
070
Mod Wheel
071
Breath
072
Ctl 3
073
Foot Ctl
074
PortaTime
075
Data Entry
076
Volume
077
Balance
078
Ctl 9
079
Pan
080
Xpression
081
Effect 1
082
Effect 2
083
Ctl 14
084
Ctl 15
085
General 1
...
General 2
090
General 3
091
General 4
092
Ctl 20
093
...
094
Ctl 31
095
096
Ctl 33
097
...
098
Ctl 63
099
Sustain
100
Porta On
101
Sostenuto
102
SoftPedal
...
Legato
119
Hold 2
The Algorithms and Their Parameters

Patching

Sound Var
Timbre
Release
Attack
Bright
Sound 6
Sound 7
Sound 8
Sound 9
Sound 10
General 5
General 6
General 7
General 8
Porta Ctl
Ctl 85
...
Ctl 90
FX1 Depth
FX2 Depth
FX3 Depth
FX4 Depth
FX5 Depth
Data Inc
Data Dec
NRPN LSB
NRPN MSB
RPN LSB
RPN MSB
Ctl 102
...
Ctl 119
