Each PCM 81 preset has a unique soft knob patch that allows you to control the
effect directly from Program or Register Banks mode with the ADJUST knob.
You can also control the soft knob patch remotely from MIDI, or from the Foot
Pedal.
To control the soft knob with MIDI, set Control mode 3.1 (Receive) to the desired
MIDI Channel. Set Control mode 3.5 (ADJUST) to the desired MIDI Controller
such as Mod Wheel.
MIDI
3.5 Send
Now, the Mod Wheel on the MIDI instrument will control the soft knob patch of
the running effect.
If you have a foot pedal connected to the PCM rear panel Foot Controller jack,
you can use it to control the soft knob patch. (Note that no MIDI connections are
required to do this.)
Set both Control mode 3.5 ADJUST and Control mode 3.5 Foot Pedal to the
same MIDI Controller.
MIDI
3.5 Send
MIDI
3.5 Send
Now, the foot pedal will control the soft knob patch of the running effect.
ADJUST
Mod Wheel
ADJUST
Ctl 3
Foot Pedal
Ctl 3
MIDI Operation
Controlling the Soft Knob
with MIDI
Controlling the Soft Knob

with a Foot Pedal

5-5
