Setup
PERFORMING AUTOMATIC CALIBRATION
SETTING DISTANCES
CUSTOM SETUP
FRONT LEFT 0.0ft
CENTER 0.0ft
FRONT RIGHT 0.0ft
SIDE RIGHT 0.0ft
REAR RIGHT 0.0ft
REAR LEFT 0.0ft
SIDE LEFT 0.0ft
MONO SUB 0.0ft
SUB RIGHT
LFE
STEP DISTANCES
The SETTING DISTANCES screen displays when the MC-12 calibrates speaker distances.
• During speaker distance calibration, the MC-12 sends calibration noise signals to the Main Zone
audio output connectors in the order shown on the SETTING DISTANCES screen. The cursor auto-
matically scrolls downward through speaker calibration parameters, highlighting each parameter
while the MC-12 calculates a distance for the corresponding speaker. As it finishes each parameter,
the MC-12 enters the calibrated value or an ERROR message to the right of the parameter label.
3
• Because of the way low frequency signals propagate in most listening spaces, automatic speaker dis-
tance calibration often produces unreliable results for subwoofers and LFE subwoofers. For this reason
the MC-12 does not send calibration noise signals to the Subwoofer L/R and LFE output connectors
during speaker distance calibration. Instead, the MC-12 automatically calibrates subwoofer and LFE
subwoofer distances to the shortest distance of the other speakers. These distances can be manually
adjusted. See "PERFORMING MANUAL SPEAKER DISTANCE CALIBRATION" on page 3-53.
This step does not occur when the AUTO SPEAKER
SETUP menu DISTANCES option is selected.
4
3-48
(continued)
SETTING DISTANCES
CUSTOM SETUP
FRONT LEFT 12.0ft
CENTER 10.5ft
FRONT RIGHT 12.0ft
SIDE RIGHT 4.5ft
REAR RIGHT ERROR
REAR LEFT 6.0ft
SIDE LEFT 4.5ft
MONO SUB
N/A SUB RIGHT
N/A LFE
SETTING LEVELS
CUSTOM SETUP
FRONT LEFT
CENTER
FRONT RIGHT
SIDE RIGHT
REAR RIGHT
REAR LEFT
SIDE LEFT
N/A MONO SUB
N/A SUB RIGHT
N/A LFE
DISTANCES & LEVELS
The SETTING LEVELS screen displays when the MC-12 calibrates output levels.
• The MC-12 sends calibration noise signals to the Main Zone audio output connectors in the
order shown on the SETTING LEVELS screen. The cursor automatically scrolls downward
through speaker calibration parameters, highlighting each parameter while the MC-12 calcu-
lates an output level for the corresponding speaker. As it finishes each parameter, the MC-12
enters the calibrated value or an ERROR message to the right of the parameter label.
SETTING LEVELS
CUSTOM SETUP
0.0dB FRONT LEFT -2.0dB
0.0dB CENTER ERROR
0.0dB FRONT RIGHT -2.0dB
0.0dB SIDE RIGHT -4.5dB
0.0dB REAR RIGHT -3.0dB
0.0dB REAR LEFT -3.0dB
0.0dB SIDE LEFT -4.5dB
0.0dB MONO SUB
N/A SUB RIGHT
N/A LFE
LEVELS
This step does not occur when the AUTO
SPEAKER SETUP menu LEVELS option is
selected.
