Summarization of Contents
General Features
Natural Gas Models
Certification for natural and L.P. gas by AGA/CSA standards.
Safe Operation
Solid-state control monitors flame; dual solenoid gas valve enhances safety.
Quick Heating
Durable, heavy gauge aluminized steel heat exchanger for efficient heat transfer.
Burners
Multi-port in-shot burners offer quiet, efficient service and L.P. conversion.
Integrated System Control
Solid-state control manages limits, blowers, flame; includes self-diagnostics.
Air Delivery
4-speed blower motor provides flexible airflow for heating/cooling needs.
Styling
Heavy gauge steel cabinet with baked-on enamel and fiberglass insulation.
Features And General Operation
Adaptive Hot Surface Ignition eliminates pilot; front service access provided.
Features and Benefits
Standard Equipment
Lists key components like igniter, control, heat exchanger, filters, etc.
Optional Equipment
Lists optional accessories like thermostats, air filters, and coil enclosures.
General Data
Product Specifications
Detailed technical specifications for various furnace models, including ratings, blower, heat exchanger.
Performance Data
Furnace Airflow (CFM) vs. Static Pressure (ins. w.g.)
Tables detailing airflow rates at different static pressures for various speed taps.
Cfm Vs. Temperature Rise
Tables showing CFM values for different temperature rises across various furnace models.
Field Wiring
Field Wiring Diagram For Heating Only
Wiring diagram for heating-only configurations with thermostat and optional accessories.
Field Wiring Diagram For Single Stage Heating/Cooling (Outdoor Section Without Transformer)
Wiring diagram for heating/cooling with outdoor unit, excluding transformer.
Twinning Field Wiring
Twinning Connection Diagram For Twinning 1 Stage Furnaces With Single Wire Twinning Feature 1 Stage Heating Only Thermostat
Diagram for twinning two heating-only furnaces with single-wire feature.
Twinning Connection Diagram For Twinning 1 Stage Furnaces With Single Wire Twinning Feature 1 Stage Heat / 1 Stage Cooling Thermostat
Diagram for twinning heating/cooling furnaces with single-wire feature.
Dimensions
TUD-C Outline Drawing
Shows overall dimensions and port locations for TUD-C models.
Minimum Clearance To Combustible Materials
Specifies required clearances for upflow, horizontal closet, and alcove installations.
Electrical Data
Schematic Diagrams for Gas Furnaces
Provides wiring diagrams and component connections for gas furnaces.
Table A Speed Taps for I.D. Fan Motor
Lists speed tap assignments for different furnace models and their corresponding motor wires.
