Chapter 4 Troubleshooting QoS Issues
S e n d d o c u m e n t c o m m e n t s t o n e x u s 5 k - d o c f e e d b a c k @ c i s c o . c o m .
Nexus 5000 10G PFC
Use the following command:
Nexus 5000 1G storm control
Use the following commands:
Nexus 5000 10G storm control
Use the following commands:
Nexus 5000 storm control counter
Use the following command:
afm-related CLI commands and tools
Commands
show platform afm in
att br
show platform afm in
att global
show platform afm in
att interface
ethernet x/y
show platform afm in
group id X asic Y
show platform afm in
map-tbls
OL-25300-01
show hard in gatos asic <gatos_num> registers match mm_CFG_pause$
show plat fwm info lif eth1/1
show plat fwm info pif eth1/1
debug hardware internal gatos asic 0 dump-mem 0x3b9000 20
show plat fwm info lif eth1/5
show plat fwm info pif eth1/5
debug hardware internal gatos asic 1 dump-mem 0x3b9000 20
show hardware internal gatos asic 1 counters rx_db 2 | grep storm
Purpose
Shows which features or groups are attached to which interface.
Shows the IDs of policies including QoS Policies (printed as NP Policies)
attached on the global interface.
Shows the IDs of policies including QoS Policies for an interface or PC.
Shows the TCAM entries for a particular group on a particular
ASIC/GATOS.
Shows the internal mapping tables, such as the ext-cos to qos-group,
qos-group to int-cos, and int-cos to class_id maps.
Cisco Nexus 5000 Series Troubleshooting Guide
Registers and Counters
4-11
