MIDI

The MIDI implementation for the Rev 1 960L is very
basic. Since the implementation is fixed, there is no
user interface for modifying it.

Nomenclature

Numbering in MIDI, i.e. channel number, program
numbers, etc., can be confusing, since some sources
start counting from zero and others start from one. This
description will start from zero. If, for example, your
Channel Usage
0 Global Channel
1 DSP Card
2 Unused
3 Unused
4 Machine 1
5 Machine 2
6 Machine 3
7 Machine 4
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
MIDI controller's lowest channel number is 1 (rather
than 0), you should add one to the values found in
channel table below.

MIDI Channel Allocation

The 960L uses a fixed channel allocation. All channels
are used or reserved, which means that 960L should
be the only device on its MIDI cable.
Description
Not currently in use
Configuration of card.
Reserved for Future Use
Reserved for Future Use
Program change for machine 1
Program change for machine 2, if present in current configuration
Program change for machine 3, if present in current configuration
Program change for machine 4, if present in current configuration
Reserved for Future Use
Reserved for Future Use
Reserved for Future Use
Reserved for Future Use
Reserved for Future Use
Reserved for Future Use
Reserved for Future Use
Reserved for Future Use

MIDI

6-1
