Main Dialogue Description - Simrad PI44 Operator's Manual

13
1
2
3
4
5
(CD11025)
ID Button/Function
1 Establish communication with
sensor
2 Read sensor data
3 Configure sensor
850-165085 / Rev.B

Main dialogue description

Observe the illustration and descriptions below. Note that the
apperance of function buttons will differ depending on the
sensor type connected to the application. When functions are
unavailable, the fields are identified accordingly with a shaded
appearance.
14
Use
Once the sensor is connected to the PC, click to initiate
sensor interface.
Click to download current parameter settings from the
sensor. The information is shown in the message field
(5).
Click to upload the new configuration parameters to the
sensor.
PI Configurator
15
16
17
18
19
6
7
8
9
10
11
12
20
22
231
