Installation

Installation
Connection to your Personal Computer
The MultiSync LCD
compatible computers. Your system has one of two configurations:
– the video controller is built into the computer.
– the video controller is in the form of a display card (sometimes
referred to as graphics card, video adapter or graphics board).
Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which connector is the video connector,
refer to your computer or display card manual.
To attach the MultiSync LCD
follow these instructions:
1. Turn off the power of your computer.
2. For the PC with DVI digital output: Connect the DVI-D to
DVI-D signal cable to the connector of the display card in your
system (Figure A.1). Tighten all screws.
For the PC with Analog output: Connect the 15-pin mini D-
SUB to DVI signal cable to the connector of the display card
in your system (Figure A.2).
To connect a secondary PC with analog output, connect the
15-pin mini D-SUB to 15-pin mini D-SUB signal cable (not
include) to the connector of the display card in your system.
For the Mac: Connect the MultiSync Macintosh cable adapter to
the computer (Figure B.1). Attach the 15-pin mini D-SUB signal
cable to the MultiSync Macintosh cable adapter (Figure B.1).
NOTE: Some Macintosh systems do not require a Macintosh cable adapter.
CN971B/LCD2010X/7A812101
true colour monitor complements PC
2010X
2010X
23
monitor to your system,
00.8.30, 2:21 PM
E - 8
