NEC MultiSync LCD2010X LCD2010X LCD2010X Specification Sheet

www.nec-monitors.com
NEC-Mitsubishi Electronics
Display-Europe GmbH
MultiSync ®
With Digital and Analog Interfaces
Display Type:
Active Display Area:
Pixel Pitch:
Viewing Angle:
Brightness:
Contrast Ratio:
Number of Colours:
Optimum Resolution:
Other Resolutions:
Features/Adjust Functions:
User Controls:
Plug & Play; Asset Management:
Horizontal Frequency:
Vertical Frequency:
Connectors:
Audio Functions:
USB Functions:
VESA Mounting Interface:
Kensington Lock:
Dimensions (W x H x D):
Screen Tilt/Swivel/Rotate:
Weight:
Power Supply:

Power Requirements:

Ambient Temperature (Operat.):
Ambient Humidity (Operating):
Safety/Ergonomics:
Warranty:
Shipping Contents:
• Professional LCD monitor with SuperFine TFT display
• ambix Technology: DVI-I interface (digital and analog) + additional VGA analog interface
• VESA mounting interface enables versatile installation
• TORO design, screen rotation by 90 degrees
• Ergonomics and safety complying to the highest industry standards including ISO 13406-2
* 3 years on-site warranty within EU countries, Switzerland, Norway, Liechtenstein and Iceland; with optional exchange or repair and return service.
Pivot® and the Pivot Enabled™ logo are registered trademarks of Portrait Displays, Inc. Copyright 1999 Portrait Displays, Inc. All rights reserved.
All specifications are subject to change without notice. Status October 2000
LCD2010X
SuperFine TFT; 20.1 inch
399 x 320 mm
0.31 x 0.31 mm
170° horizontal/170° vertical (at contrast ratio 10:1)
250 cd/m 2 typ.
250:1 typ.
16.77 million
1280 x 1024 at 60 Hz
1152 x 900; 1024 x 768; 832 x 624; 800 x 600; 720 x 400; 640 x 480
Auto adjust; Contrast; Brightness; Fine adjust; Colour control; Monitor
info; Language select; Intelligent Power Management (VESA/EPA/NUTEK
compliant) disable; Headphone volume; OSM lock out
On/Off; OSM menu; Interfaces
VESA DDC1; DDC2B and EDID standard
31–82 kHz
56–85 Hz
Analog: Mini D-sub 15 pin
Headphone jack
No
Yes; 100 x 100 mm
Yes
498 x 501 x 246 mm (landscape format)
-5° to +30° / 350° / -45° to +45°; TORO design: screen rotation 90°
11.0 kg
100-240 V; 0.7/0.3 A
63 W max. On mode; < 3.3 W power saving mode
+5 °C to +35 °C
30–80 % (non-condensing)
CE; TÜV GS; TÜV ERGONOMIE; UL; CSA; ISO 13406-2; TCO 99;
Energy Star
3 years warranty including backlights; 3 years on-site warranty*
Monitor; DVI-I to VGA signal cable; DVI-D signal cable; User manual;
Pivot® software
Digital: DVI-I connector
