- Page 4 INSTALLATION MANUAL 401724 Grip Step Bracket kit 2015+ Ford Transit Van Long\Long Parts List Level of Difficulty Front Mounting Bracket Easy Middle Mounting Bracket Rear Mounting Bracket Product Image AC Mounting Bracket AC Top Mounting Bracket UBolt 3" UBolt 3.75" Spacer Bolt Retainer Lock Washer, 5/16...
- Page 5 Step 1 Starting on the Passanger side, locate mounting locations as shown in Fig 1 and Fig 3. Hold each bracket in its mounting locations and mark each hole on the rocker and pinch weld. Step 2 From the under side of the plastic rocker molding use a flat head screw drive to release the bottom push pins.
- Page 6 Step 5 Move to the 3rd & 4th mounting brackets, models with factory studs will use those as monting locations. Models with out factory studs will have holes pre drilled in the rocker panel and will use the 3.75" UBolts with the plastic bolt retainer.
- Page 7 Step 8 Assemble the AC bracket using the (2) M8 Bolts, (2) 5/16 washers, (2) M8 nuts. Step 9 After assembling the AC bracket place along the pinch seam using Fig. 2 and Fig. 4 marking the 4 hole locations Step 10 Drill the 2 upper holes with a 19/64 drill bit and the bottom 2 19/64 with a 3/8 drill bit...
