Specifications

Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DVI:
DisplayPort:
DisplayPort Connector:
VGA:
15pin Mini D-sub:
Display Colours
Synchronization Range
Viewing Angle
Resolutions Supported
Active
Landscape: Horiz.:
Display Area
USB Hub
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
Headphone Output:
STEREO Mini Jack:
Speakers
Practical Audio Output:
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifications are subject to change without notice.
MultiSync EA231WMi
Diagonal:
58.4 cm/23.0 inches
58.4 cm/23.0 inches
1920 x 1080
DVI-D 24pin:
Digital RGB
Digital RGB
Analog RGB
Sync
16,777,216
Horizontal:
31.5 kHz to 83 kHz
Vertical:
56.0 Hz to 76.0 Hz (Over SXGA: 60Hz)
Left/Right:
±89° (CR > 10)
Up/Down:
±89° (CR > 10)
720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 870*
1280 x 1024*
1400 x 1050*
1440 x 900*
1920 x 1080 @ 60 Hz............................. NEC DISPLAY SOLUTIONS cites recommended.
510 mm/20.0 inches
Vert.:
287 mm/11.3 inches
Portrait: Horiz.:
287 mm/11.3 inches
Vert.:
510 mm/20.0 inches
I/P:
USB Specification Revision 2.0
Port:
Upstream 1
Downstream 4
Load Current:
Maximum 0.5A per port
Analog Audio
Digital Audio
1.0 W + 1.0 W
AC 100-240 V ~ 50/60 Hz
1.05-0.55 A (with USB and Audio)
Landscape:
550.1 mm (W) x 379.1 - 489.1 mm (H) x 220.0 mm (D)
21.7 inches (W) x 14.9 - 19.3 inches (H) x 8.7 inches (D)
Portrait:
329.0 mm (W) x 565.1 - 600.6 mm (H) x 220.0 mm (D)
13.0 inches (W) x 22.2 - 23.6 inches (H) x 8.7 inches (D)
110.0 mm/4.3 inches (Landscape condition)
35.5 mm/1.4 inches (Portrait condition)
8.5 kg (18.7 lbs)
5°C to 35°C / 41°F to 95°F
Humidity:
20% to 80%
Altitude:
0 to 6,562 Feet / 0 to 2,000 m
-10°C to 60°C / 14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet / 0 to 12,192 m
1
: VGA text
1
@ 60 Hz to 75 Hz
1
@ 56 Hz to 75 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 75 Hz
1
@ 60 Hz to 75 Hz
1
@ 60 Hz
1
@ 60 Hz
English-14
Notes
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.265 mm dot pitch; 270 cd/m
luminance; 1000:1 contrast ratio, typical
(3000:1 contrast ratio, Dynamic).
DVI (HDCP)
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
Depends on display card used.
Automatically
Automatically
Some systems may not support all modes listed.
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 KHz (16/20/24bit)
Headphone Impedance 32 Ohm
2
white
