Baxton Studio Stella BBT 3084 Assembly Instructions

MODEL : BBT 3084
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
STEP 1
A
STEP 3
ASSEMBLY INSTRUCTIONS
ITEM
A
B
C
D
E
F
STEP 2
F
1
STEP 4
C
B
E
D
PART LIST
QTY
DESCRIPTION ITEM
NIGHTSTAND 1 SET 1
HANDLE 2 PCS 2
HANDLE SCREW 2 PCS
FLAT WASHER 2 PCS
DRAWER 2 PCS
LEGS 4 PCS
PART LIST
DESCRIPTION QTY
Wood Screw M4 x 20mm 12 PCS
-
C
B
E
D
