Baxton Studio Davina BBT3119 Assembly Instructions

MODEL : BBT3119 NIGHT STAND MODEL : BBT 3119 Night Stand
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
STEP 1
A
1
STEP 3
ASSEMBLY INSTRUCTIONS
F
C
D
PART LIST
ITEM DESCRIPTION
A
LEGS
B HANDLE
C
HANDLE SCREW
D FLAT WASHER
E
DRAWER
F NIGHTSTAND
STEP 2
STEP 4
B
E
PART LIST
QTY ITEM DESCRIPTION
1
WOOD SCREW M4 x 45mm
4 PCS
2 PCS
2 PCS
2 PCS
2 PCS
1 PC
B
E
QTY
4 PCS
C
D
