modway Emily MOD-5170 Assembly Instructions

MOD - 5170
Read this instruction carefully. See furniture and hardware part lists,
on the right, for guidance.
Have all parts ready befor e assembly. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the steps below to start assembling.
CAUTION
1. Do not FULLY - TIGHTEN the nut or bolt until all nuts and bolt s are assembled.
:
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
STEP 1
A
Align support board fixing holes over headboard
fixing holes according to your desired height.
STEP 3
Your headboard assembly is complete.
Note: Hardware may loosen over time. Periodically
check that all connections are tight.
ASSEMBLY INSTRUCTIONS
FURNITURE PART LIST
ITEM
A
B
STEP 2
B
Secure the support board by using JCBB Bolt [1]
& flat washer [2]. Tighten with supplied allen key
[3]. Repeat the same procedure to secure the
other side.
QTY ITEM
DESCRIPTION
1 JCBB BOLT M8 x 40mm
HEADBOARD 1 PC
2 M8 FLAT WASHER
SUPPORT BOARD 2 PCS
3
M5 ALLEN KEY
HARDWARE PART LIST
QTY
DESCRIPTION
4 PCS
4 PCS
1 PC
3
1
2
