Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
Page 1
Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
2013-2016 Scion FR-S BaSe RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 PROGRAMMED FIRMWARE...
Page 3
Scion FR-S BaSe 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 5
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 8
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 10
2013-2016 Scion FR-S with Amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 11
Scion FR-S with Amp 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 16
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 17
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 18
2013-2016 Scion FR-S with nAV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 19
Scion FR-S with nAV 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 21
BLUE CONTROL CABLE WIRES FROM GREEN VEHICLE WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 24
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 25
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 26
Scion FR-S with nAV with Amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 27
Scion FR-S with nAV with Amp 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 32
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 33
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 34
2013-2020 Subaru brZ baSe RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 PROGRAMMED FIRMWARE...
Page 35
Subaru brZ baSe 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 37
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 40
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 41
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 42
2013-2020 Subaru brZ with amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 43
Subaru brZ with amp 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 48
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 49
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 50
2013-2020 Subaru brZ with NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 51
Subaru brZ with NaV 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 53
BLUE CONTROL CABLE WIRES FROM GREEN VEHICLE WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 56
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 57
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 58
Subaru brZ with NaV with amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 59
Subaru brZ with NaV with amp 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 64
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 65
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 66
Subaru ForeSter with 6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 67
Subaru ForeSter with 6.2 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 69
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 72
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 73
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 74
Subaru ForeSter with 6.2 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 75
Subaru ForeSter with 6.2 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 80
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 81
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru ForeSter with 6.5 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 83
Subaru ForeSter with 6.5 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 84
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 85
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 88
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 89
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 90
Subaru ForeSter with 6.5 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 91
Subaru ForeSter with 6.5 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 92
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 93
PURPLE WHITE WHITE unplug GRAY STEP 6 BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW MAESTRO RR MODULE CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON...
Page 96
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 97
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru ForeSter with 7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 99
Subaru ForeSter with 7 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 101
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 104
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 105
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 106
Subaru ForeSter with 7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 107
Subaru ForeSter with 7 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 108
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 109
WHITE GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 112
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 113
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 114
Subaru ForeSter with 7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 115
Subaru ForeSter with 7 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 117
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 120
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 121
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 122
Subaru ForeSter with 7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 123
Subaru ForeSter with 7 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 124
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 125
GREEN STEERING WHEEL CONTROL CABLE WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN...
Page 128
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 129
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
2014-2015 Subaru ForeSter with NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 131
Subaru ForeSter with NaV 2014-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 133
GREEN CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED WITH A BACKUP CAMERA WHITE BLUE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED...
Page 136
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 137
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 138
Subaru ForeSter with NaV aNd harmaN KardoN RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 139
Subaru ForeSter with NaV aNd harmaN KardoN 2014-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 141
WIRES FROM STEERING WHEEL VEHICLE CONTROL CABLE CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED YELLOW WITH A BACKUP CAMERA STEP 5 BLUE GRAY MAESTRO RR MODULE WHITE PURPLE GREEN WHITE STEP 3 OBDII CONNECTOR STARLINK STARLINK GREEN AMP TURN ON...
Page 144
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 145
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 146
Subaru ForeSter with NaV aNd Sd card RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 147
Subaru ForeSter with NaV aNd Sd card 2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 149
FACTORY RADIO HARNESS YELLOW STEERING WHEEL CONTROL CABLE BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 152
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 153
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 154
Subaru ForeSter with NaV aNd uSb RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 155
Subaru ForeSter with NaV aNd uSb 2013 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 157
FACTORY RADIO HARNESS YELLOW STEERING WHEEL CONTROL CABLE BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 160
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 161
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 162
Subaru Impreza wIth 6.2 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 163
Subaru Impreza wIth 6.2 Inch Screen 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 165
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 168
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 169
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 170
Subaru Impreza wIth 6.2 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 171
Subaru Impreza wIth 6.2 Inch Screen and harman Kardon 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 176
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 177
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru Impreza wIth 7 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 179
Subaru Impreza wIth 7 Inch Screen 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 181
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 184
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 185
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 186
Subaru Impreza wIth 7 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 187
Subaru Impreza wIth 7 Inch Screen and harman Kardon 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 189
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 192
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 193
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 194
NaV aNd harmaN KardoN aNd oem camera oN radIo RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 195
Subaru Impreza wIth NaV aNd harmaN KardoN aNd oem camera oN radIo 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 197
FACTORY RADIO HARNESS YELLOW BLUE STEERING WHEEL WIRES FROM CONTROL CABLE VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE STARLINK STARLINK STEP 3 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 200
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 201
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
NaV aNd harmaN KardoN aNd oem camera oN SecoNdary dISplay RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 203
Subaru Impreza wIth NaV aNd harmaN KardoN aNd oem camera oN SecoNdary dISplay 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 205
WIRES FROM STEERING WHEEL VEHICLE CONTROL CABLE CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED YELLOW WITH A BACKUP CAMERA STEP 5 BLUE GRAY MAESTRO RR MODULE WHITE PURPLE GREEN WHITE STEP 3 OBDII CONNECTOR STARLINK STARLINK GREEN AMP TURN ON...
Page 208
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 209
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 210
Subaru Impreza wIth NaV aNd Oem camera ON radIO RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 211
Subaru Impreza wIth NaV aNd Oem camera ON radIO 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 213
FACTORY RADIO HARNESS YELLOW STEERING WHEEL CONTROL CABLE BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 216
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 217
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 218
Subaru Impreza wIth NaV aNd Oem camera ON SecONdary dISplay RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 219
Subaru Impreza wIth NaV aNd Oem camera ON SecONdary dISplay 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 221
GREEN CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED WITH A BACKUP CAMERA WHITE BLUE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED...
Page 224
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 225
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru Legacy with 6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 227
Subaru Legacy with 6.2 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 229
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 232
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 233
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 234
Subaru Legacy with 6.2 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 235
Subaru Legacy with 6.2 inch Screen and harman Kardon 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 240
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 241
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru Legacy with 7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 243
Subaru Legacy with 7 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 245
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 248
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 249
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 250
Subaru Legacy with 7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 251
Subaru Legacy with 7 inch Screen and harman Kardon 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 253
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 256
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 257
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 258
Subaru Outback with 6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 259
Subaru Outback with 6.2 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 261
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 264
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 265
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 266
Subaru Outback with 6.2 inch Screen and harman kardOn RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 267
Subaru Outback with 6.2 inch Screen and harman kardOn 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 272
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 273
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru Outback with 7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 275
Subaru Outback with 7 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 277
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 280
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 281
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 282
Subaru Outback with 7 inch Screen and harman kardOn RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 283
Subaru Outback with 7 inch Screen and harman kardOn 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 285
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 288
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 289
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru WrX STI WITh 6.2 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 291
Subaru WrX STI WITh 6.2 Inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 293
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 296
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 297
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 298
Subaru WrX STI WITh 6.2 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 299
Subaru WrX STI WITh 6.2 Inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 304
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 305
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 306
Subaru WrX STI WITh 6.5 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 307
Subaru WrX STI WITh 6.5 Inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 308
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 309
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 312
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 313
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 314
Subaru WrX STI WITh 6.5 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 315
Subaru WrX STI WITh 6.5 Inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 316
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 317
PURPLE WHITE WHITE unplug GRAY STEP 6 BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW MAESTRO RR MODULE CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON...
Page 320
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 321
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 322
Subaru WrX STI WITh 6.5 Inch Screen WIThouT aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 323
Subaru WrX STI WITh 6.5 Inch Screen WIThouT aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 324
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 325
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE 24 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 328
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 329
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 330
Subaru WrX STI WITh 7 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 331
Subaru WrX STI WITh 7 Inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 333
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 336
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 337
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 338
Subaru WrX STI WITh 7 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 339
Subaru WrX STI WITh 7 Inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 340
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 341
WHITE GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 344
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 345
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 346
Subaru WrX STI WITh 7 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 347
Subaru WrX STI WITh 7 Inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 349
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 352
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 353
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 354
Subaru WrX STI WITh 7 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 355
Subaru WrX STI WITh 7 Inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 356
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 357
GREEN STEERING WHEEL CONTROL CABLE WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN...
Page 360
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 361
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 362
Subaru WrX STI WITh 7 Inch Screen WIThouT aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 363
Subaru WrX STI WITh 7 Inch Screen WIThouT aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 364
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 365
CONTROL CABLE WIRES FROM VEHICLE WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 24 GREEN...
Page 368
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 369
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 370
Subaru WrX STI WITh NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 371
Subaru WrX STI WITh NaV 2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 373
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 376
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 377
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 378
Subaru WrX STI WITh NaV aNd amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 379
Subaru WrX STI WITh NaV aNd amp 2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 381
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 384
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 385
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 386
Subaru WrX With 6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 387
Subaru WrX With 6.2 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 389
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 392
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 393
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 394
Subaru WrX With 6.2 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 395
Subaru WrX With 6.2 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 400
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 401
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 402
Subaru WrX With 6.5 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 403
Subaru WrX With 6.5 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 404
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 405
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 408
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 409
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 410
Subaru WrX With 6.5 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 411
Subaru WrX With 6.5 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 412
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 413
PURPLE WHITE WHITE unplug GRAY STEP 6 BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW MAESTRO RR MODULE CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON...
Page 416
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 417
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 418
Subaru WrX With 6.5 inch Screen Without aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 419
Subaru WrX With 6.5 inch Screen Without aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 420
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 421
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE 24 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 424
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 425
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 426
Subaru WrX With 7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 427
Subaru WrX With 7 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 429
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 432
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 433
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 434
Subaru WrX With 7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 435
Subaru WrX With 7 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 436
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 437
WHITE GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 440
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 441
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 442
Subaru WrX With 7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 443
Subaru WrX With 7 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 445
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 448
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 449
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 450
Subaru WrX With 7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 451
Subaru WrX With 7 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 452
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 453
GREEN STEERING WHEEL CONTROL CABLE WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN...
Page 456
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 457
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 458
Subaru WrX With 7 inch Screen Without aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 459
Subaru WrX With 7 inch Screen Without aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 460
INSTALLATION INSTRUCTIONS P1 /1 STEP 6 STEP 1 • Connect all the harnesses to the Maestro RR module then Remove the factory radio test your installation. If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2.
Page 461
CONTROL CABLE WIRES FROM VEHICLE WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 24 GREEN...
Page 464
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 465
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 466
2015 Subaru WrX With NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 467
Subaru WrX With NaV 2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 469
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 472
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 473
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 474
Subaru WrX With NaV aNd amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 475
Subaru WrX With NaV aNd amp 2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 477
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 480
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 481
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 482
Subaru XV CroSStrek with 6.2 inCh SCreen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 483
Subaru XV CroSStrek with 6.2 inCh SCreen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 485
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 488
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 489
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 490
Subaru XV CroSStrek with 6.2 inCh SCreen and harman kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 491
Subaru XV CroSStrek with 6.2 inCh SCreen and harman kardon 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 496
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 497
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru XV CroSStrek with 7 inCh SCreen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 499
Subaru XV CroSStrek with 7 inCh SCreen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 501
FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN STEERING WHEEL CONTROL CABLE WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 504
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 505
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 506
Subaru XV CroSStrek with 7 inCh SCreen and harman kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 507
Subaru XV CroSStrek with 7 inCh SCreen and harman kardon 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 509
BLUE CONTROL CABLE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 512
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 513
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 514
Subaru XV CroSStrek with harman kardon and oem Camera on radio RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 515
Subaru XV CroSStrek with harman kardon and oem Camera on radio 2013-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 517
FACTORY RADIO HARNESS YELLOW BLUE STEERING WHEEL WIRES FROM CONTROL CABLE VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE STARLINK STARLINK STEP 3 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 520
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 521
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
NaV aNd harmaN kardoN aNd oem Camera oN SeCoNdary diSplay RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 523
Subaru XV CroSStrek with NaV aNd harmaN kardoN aNd oem Camera oN SeCoNdary diSplay WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 525
WIRES FROM STEERING WHEEL VEHICLE CONTROL CABLE CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED YELLOW WITH A BACKUP CAMERA STEP 5 BLUE GRAY MAESTRO RR MODULE WHITE PURPLE GREEN WHITE STEP 3 OBDII CONNECTOR STARLINK STARLINK GREEN AMP TURN ON...
Page 528
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 529
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 530
Subaru XV CroSStrek with NaV aNd oeM CaMera oN SeCoNdary diSplay RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER:...
Page 531
Subaru XV CroSStrek with NaV aNd oeM CaMera oN SeCoNdary diSplay 2013-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 533
GREEN CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED WITH A BACKUP CAMERA WHITE BLUE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED...
Page 536
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 537
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Subaru XV CroSStrek with oeM CaMera on radio RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 539
Subaru XV CroSStrek with oeM CaMera on radio 2013-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 541
FACTORY RADIO HARNESS YELLOW STEERING WHEEL CONTROL CABLE BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED DATA AUDIO...
Page 544
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 545
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 546
2017-2020 ToyoTa 86 Base RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1 PROGRAMMED FIRMWARE...
Page 547
ToyoTa 86 Base 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 549
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 552
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 553
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 554
2017-2020 ToyoTa 86 wiTh amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 555
ToyoTa 86 wiTh amp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 560
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 561
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 562
2017-2020 ToyoTa 86 wiTh NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 563
ToyoTa 86 wiTh NaV 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 565
BLUE CONTROL CABLE WIRES FROM GREEN VEHICLE WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 568
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 569
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 570
ToyoTa 86 wiTh NaV wiTh amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-uSU2 iDatalink Maestro HRR-SU2 Installation Harness Non-iDatalink compatible radio HEAD UNIT ADAPTER: ACC-HU-PIO1, SON1, KEN1, KEN2, ALP1...
Page 571
ToyoTa 86 wiTh NaV wiTh amp 2017-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 576
BROWN/RED and BROWN/YELLOW wires need to be cut in the harness. diagram). Maestro RR side of those wires should be extended to the climate control harness, as shown in the diagram. CAN wires should be next to each other in the plug, not on top of one another.
Page 577
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 578
Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
Page 579
BaSe RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 580
Scion FR-S BaSe 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 582
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 585
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 586
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 587
Amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 588
Scion FR-S with Amp 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 593
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 594
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 595
RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 596
Scion FR-S with nAV 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 598
YELLOW BLUE WIRES FROM GREEN VEHICLE WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 601
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 602
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 603
Amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 604
Scion FR-S with nAV with Amp 2013-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 609
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 610
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 611
RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 612
Subaru brZ baSe 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 614
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 617
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 618
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 619
RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 620
Subaru brZ with amp 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 625
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 626
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 627
NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 628
Subaru brZ with NaV 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 630
YELLOW BLUE WIRES FROM GREEN VEHICLE WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 633
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 634
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 635
NaV with amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 636
Subaru brZ with NaV with amp 2013-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 641
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 642
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 643
6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 644
Subaru ForeSter with 6.2 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 646
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 649
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 650
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 651
6.2 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 652
Subaru ForeSter with 6.2 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 657
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 658
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
6.5 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 660
Subaru ForeSter with 6.5 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 661
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 662
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 665
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 666
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 667
6.5 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 668
Subaru ForeSter with 6.5 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 669
If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2. • Connect all the harnesses to the Maestro RR module then test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 670
PURPLE WHITE WHITE unplug GRAY STEP 6 BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW MAESTRO RR MODULE CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON...
Page 673
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 674
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 676
Subaru ForeSter with 7 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 678
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 681
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 682
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 683
7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 684
Subaru ForeSter with 7 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 685
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 686
WHITE GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 689
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 690
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 691
7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 692
Subaru ForeSter with 7 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 694
YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 697
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 698
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 699
7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 700
Subaru ForeSter with 7 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 701
If using head unit adapter (sold separately), connect HRR- STEP 6 SU2 harness to adapter and skip to step 2. • Connect all the harnesses to the Maestro RR module then test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 702
WHITE WIRES FROM VEHICLE GREEN WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN...
Page 705
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 706
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 707
NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 708
Subaru ForeSter with NaV 2014-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 710
GREEN CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED WITH A BACKUP CAMERA WHITE BLUE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED...
Page 713
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 714
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 715
NaV aNd harmaN KardoN RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 716
Subaru ForeSter with NaV aNd harmaN KardoN 2014-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 718
BACKUP CAM BACKUP CAM WIRES FROM VEHICLE CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED YELLOW WITH A BACKUP CAMERA STEP 5 BLUE GRAY MAESTRO RR MODULE WHITE PURPLE GREEN WHITE STEP 3 OBDII CONNECTOR STARLINK STARLINK GREEN AMP TURN ON...
Page 721
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 722
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 723
NaV aNd Sd card RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 724
Subaru ForeSter with NaV aNd Sd card 2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 726
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 729
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 730
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 731
NaV aNd uSb RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 732
Subaru ForeSter with NaV aNd uSb 2013 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 734
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 737
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 738
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 739
6.2 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 740
Subaru Impreza wIth 6.2 Inch Screen 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 742
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 745
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 746
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 747
6.2 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 748
Subaru Impreza wIth 6.2 Inch Screen and harman Kardon 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 753
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 754
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 755
7 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 756
Subaru Impreza wIth 7 Inch Screen 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 758
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 761
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 762
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 763
7 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 764
Subaru Impreza wIth 7 Inch Screen and harman Kardon 2015-2016 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 766
YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 769
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 770
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 771
NaV aNd harmaN KardoN aNd oem camera oN radIo RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 772
Subaru Impreza wIth NaV aNd harmaN KardoN aNd oem camera oN radIo 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 774
BACKUP CAM FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE STARLINK STARLINK STEP 3 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS STEERING WHEEL NOT REQUIRED...
Page 777
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 778
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 779
NaV aNd harmaN KardoN aNd oem camera oN SecoNdary dISplay RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides...
Page 780
Subaru Impreza wIth NaV aNd harmaN KardoN aNd oem camera oN SecoNdary dISplay 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 782
BACKUP CAM BACKUP CAM WIRES FROM VEHICLE CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED YELLOW WITH A BACKUP CAMERA STEP 5 BLUE GRAY MAESTRO RR MODULE WHITE PURPLE GREEN WHITE STEP 3 OBDII CONNECTOR STARLINK STARLINK GREEN AMP TURN ON...
Page 785
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 786
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 787
NaV aNd Oem camera ON radIO RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 788
Subaru Impreza wIth NaV aNd Oem camera ON radIO 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 790
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 793
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 794
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 795
NaV aNd Oem camera ON SecONdary dISplay RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 796
Subaru Impreza wIth NaV aNd Oem camera ON SecONdary dISplay 2012-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 798
GREEN CONNECT TO SECONDARY SCREEN HARNESS IF EQUIPPED WITH A BACKUP CAMERA WHITE BLUE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED...
Page 801
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 802
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 803
6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 804
Subaru Legacy with 6.2 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 806
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 809
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 810
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 811
6.2 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 812
Subaru Legacy with 6.2 inch Screen and harman Kardon 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 817
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 818
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 819
7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 820
Subaru Legacy with 7 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 822
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 825
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 826
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 827
7 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 828
Subaru Legacy with 7 inch Screen and harman Kardon 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 830
YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 833
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 834
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 835
6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 836
Subaru Outback with 6.2 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 838
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 841
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 842
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 843
6.2 inch Screen and harman kardOn RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 844
Subaru Outback with 6.2 inch Screen and harman kardOn 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 849
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 850
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 851
7 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 852
Subaru Outback with 7 inch Screen 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 854
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 857
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 858
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 859
7 inch Screen and harman kardOn RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 860
Subaru Outback with 7 inch Screen and harman kardOn 2015-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 862
YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 865
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 866
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 867
WITh 6.2 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 868
Subaru WrX STI WITh 6.2 Inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 870
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 873
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 874
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 875
WITh 6.2 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 876
Subaru WrX STI WITh 6.2 Inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 881
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 882
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 883
WITh 6.5 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 884
Subaru WrX STI WITh 6.5 Inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 885
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 886
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 889
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 890
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 891
WITh 6.5 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 892
Subaru WrX STI WITh 6.5 Inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 893
If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2. • Connect all the harnesses to the Maestro RR module then test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 894
PURPLE WHITE WHITE unplug GRAY STEP 6 BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW MAESTRO RR MODULE CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON...
Page 897
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 898
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 899
WITh 6.5 Inch Screen WIThouT aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 900
Subaru WrX STI WITh 6.5 Inch Screen WIThouT aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 901
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 902
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE 24 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 905
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 906
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 907
WITh 7 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 908
Subaru WrX STI WITh 7 Inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 910
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 913
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 914
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 915
WITh 7 Inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 916
Subaru WrX STI WITh 7 Inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 917
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 918
WHITE GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 921
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 922
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 923
WITh 7 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 924
Subaru WrX STI WITh 7 Inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 926
YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 929
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 930
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 931
WITh 7 Inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 932
Subaru WrX STI WITh 7 Inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 933
If using head unit adapter (sold separately), connect HRR- STEP 6 SU2 harness to adapter and skip to step 2. • Connect all the harnesses to the Maestro RR module then test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 934
WHITE WIRES FROM VEHICLE GREEN WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN...
Page 937
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 938
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 939
WITh 7 Inch Screen WIThouT aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 940
Subaru WrX STI WITh 7 Inch Screen WIThouT aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 941
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 942
GREEN BLUE WIRES FROM VEHICLE WHITE WHITE unplug STEP 6 PURPLE GRAY BROWN/RED BROWN/RED MAESTRO RR MODULE GRAY BROWN/YELLOW BROWN/YELLOW CLIMATE CONTROL CONNECTOR BLUE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 24 GREEN...
Page 945
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 946
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 947
WITh NaV RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 948
Subaru WrX STI WITh NaV 2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 950
STEP 2 FACTORY RADIO HARNESS YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 5 WHITE PURPLE MAESTRO RR MODULE GREEN STEP 3 OBDII CONNECTOR STARLINK STARLINK AMP TURN ON AMP TURN ON BLACK HRR-SU2 T-HARNESS NOT REQUIRED STEERING WHEEL...
Page 953
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 954
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 955
WITh NaV aNd amp RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 956
Subaru WrX STI WITh NaV aNd amp 2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 958
YELLOW BLUE WIRES FROM VEHICLE GREEN WHITE GRAY STEP 6 WHITE PURPLE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 STEP 4 OBDII CONNECTOR GREEN AMP TURN ON AMP TURN ON...
Page 961
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 962
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 963
With 6.2 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 964
Subaru WrX With 6.2 inch Screen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 966
GREEN YELLOW VEHICLE BLUE WHITE GRAY WHITE PURPLE STEP 6 STEP 3 MAESTRO RR MODULE 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON BLACK...
Page 969
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 970
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 971
With 6.2 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 972
Subaru WrX With 6.2 inch Screen and harman Kardon 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 977
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 978
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 979
With 6.5 inch Screen RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 980
Subaru WrX With 6.5 inch Screen 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 981
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 982
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Page 985
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 986
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 987
With 6.5 inch Screen and harman Kardon RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 988
Subaru WrX With 6.5 inch Screen and harman Kardon 2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 989
If using head unit adapter (sold separately), connect HRR- SU2 harness to adapter and skip to step 2. • Connect all the harnesses to the Maestro RR module then test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 990
PURPLE WHITE WHITE unplug GRAY STEP 6 BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW MAESTRO RR MODULE CLIMATE CONTROL CONNECTOR BLUE STEP 3 8 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE - 08 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON...
Page 993
The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
Page 994
TROUBLESHOOTING TABLE P2 /2 MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 995
With 6.5 inch Screen Without aMP RETAINS STEERING WHEEL CONTROLS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-SU2 Installation Harness Radar Installation Guides E L E C T R O N I C S...
Page 996
Subaru WrX With 6.5 inch Screen Without aMP 2019-2021 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
Page 997
STEP 6 Remove the factory radio If using head unit adapter (sold separately), connect HRR- • Connect all the harnesses to the Maestro RR module then SU2 harness to adapter and skip to step 2. test your installation. • Unbox the aftermarket radio and locate its main harness.
Page 998
GRAY BROWN/RED BROWN/RED GRAY BROWN/YELLOW BROWN/YELLOW STEP 6 CLIMATE CONTROL CONNECTOR BLUE MAESTRO RR MODULE STEP 3 28 PIN CONNECTOR BEHIND OEM RADIO STARLINK STARLINK PINK OR WHITE/BLUE 24 GREEN STEP 4 OBDII CONNECTOR AMP TURN ON AMP TURN ON...
Need help?
Do you have a question about the maestro Rr and is the answer not in the manual?
Questions and answers
