MULTIFUNCTIONAL STRENGTH
TRAINING HOME GYM
SF-HG92401
USER MANUAL
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).
Advertisement
Table of Contents
Related Manuals for Sunny Health & Fitness SF-HG92401
Summary of Contents for Sunny Health & Fitness SF-HG92401
- Page 1 MULTIFUNCTIONAL STRENGTH TRAINING HOME GYM SF-HG92401 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly. -
Page 3: Pre-Assembly Check List
PRE-ASSEMBLY CHECK LIST Before you start to assemble, please make sure all parts are included. - Page 4 Description Spec. Qty. Description Spec. Qty. 32* 17.2 Main Frame Nylon Swivel Sleeve *126.5 Front Stabilizer Push Rod Left Stabilizer Pulley Cover 90* 12.5 90* 12.5 Right Stabilizer 90 Pully Assembly *25.4 Rear Stabilizer Resistance Belt Hanger Left Support Tube 70 Pully Assembly 70*12.1*26 Right Support Tube...
-
Page 5: Hardware Package
HARDWARE PACKAGE SF-HG92401 HARDWARE PACKAGE SF-HG92401 HARDWARE PACKAGE... - Page 6 SF-HG92401 HARDWARE PACKAGE Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: The model number (found on cover of manual) The product name (found on cover of manual) The part number found on the “EXPLODED DIAGRAM”...
- Page 7 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 1: NOTE: It is highly recommended that you have assistance during the assembly. Attach the Left Stabilizer (No.
- Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 2: Attach the Main Frame (No. 1) to the Front Stabilizer (No. 2) using 2 Hexagon Bolts (No.
- Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 3: Attach the Main Frame (No. 1) and Rear Stabilizer (No. 5) to the Slant Support Tube (No.
- Page 10 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 4: Attach the Rotation Shaft (No. 22) and Left Power Tube (No. 24) and Right Power Tube (No.
- Page 11 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 5: Attach 2 Pulley Covers (No. 47) and Pully Assembly (No. 48) to the Main Frame (No.
- Page 12 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 7: NOTE: The installation of the spring bolt does not come with a tool, and it can be screwed into place by hand, but cannot be tightened.
- Page 13 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 8: Clamp the 4 Hanging Hook Assembly (No. 84) into the Left Support Tube (No. 11) and the Right Support Tube (No.
- Page 14 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669). STEP 9: NOTE: Assemble the Cable (No. 74) around the Right Turning Arm (No. 63) and connect with its built-in auxiliary Mini Wire (No.
- Page 15 ADJUSTMENTS AND USAGE GUIDE When adjusting the Left Turning Arm (No. 62) or the Right Turning Arm (No. 63), the hand should hold onto the Left Turning Arm (No. 62) or the Right Turning Arm (No. 63) first, then pull out the Spring Bolts (No. 60), now the Left Turning Arm (No.
-
Page 16: Exploded Diagram
EXPLODED DIAGRAM... -
Page 17: Parts List
PARTS LIST No. Description Spec. Qty. Description Spec. Qty. Main Frame Left Power Tube Front Stabilizer Right Power Tube Left Stabilizer Hexagon Bolt M12*20 Right Stabilizer Hexagon Bolt M12*70 Left Barbell Plate Rear Stabilizer Hanging Rod Right Barbell Plate Hexagon Bolt M12*75 Hanging Rod Flat Washer... - Page 18 No. Description Spec. Qty. Description Spec. Qty. Anti-Collision Pulley Cover 90* 12.5 17* 11*25 Spacer 90 Pully Assembly 90* 12.5*25.4 Outer Hexagon Bolt M10*45 Resistance Belt Flat Washer 10* 20*t2.5 Hanger 25* 20.8* Metallurgical Sleeve Hex Lock Nut 12.5 *10*3 Allen Wrench Cable 5*7420...
-
Page 19: Maintenance Instructions
MAINTENANCE INSTRUCTIONS DAILY MAINTENANCE Inspect and tighten all parts regularly. (Nuts, Bolts, Rubber Pads, Steel Brackets…etc.) Replace any worn or torn parts immediately. Check and ensure the equipment is leveled at all time. Check and tighten all adjustment pins/knobs regularly. WEEKLY MAINTENANCE Use damp cloth on plastic parts only, use dry cloth on metal frames.
