VIBRATION PLATFORM EXERCISE MACHINE
WITH RESISTANT BAND
SF-VP822056
USER MANUAL
IMPORTANT!
Please retain owner's manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US:
support@sunnyhealthfitness.com
or 1-877-90SUNNY (877-907-8669).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-VP822056 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny Health & Fitness SF-VP822056

Summary of Contents for Sunny Health & Fitness SF-VP822056

  • Page 1 VIBRATION PLATFORM EXERCISE MACHINE WITH RESISTANT BAND SF-VP822056 USER MANUAL IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED US: support@sunnyhealthfitness.com or 1-877-90SUNNY (877-907-8669).

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION We thank you for choosing our product. To ensure your safety and health, please use this equipment correctly. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using (this appliance). When using an electrical appliance, basic precautions should always be followed, including the following: DANGER – To reduce the risk of electric shock: Always unplug this appliance from the electrical outlet immediately after using and before cleaning. WARNING –...

  • Page 4: Pre-Assembly Check List

    PRE-ASSEMBLY CHECK LIST WHEN OPENING THE CARTON, YOU WILL FIND FOLLOWING PARTS: Specification Description Qty. Main Console Manual Thank You Card φ7mm Resistance Band US standard,3G0.75×1800 Power Cords Remote Control...

  • Page 5: Assembly Instruction

    ASSEMBLY INSTRUCTION We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). Turn the 2 Band Brackets (No. 20) out of the Bottom Cover (No. 29). Loosen the carabiner locks on the end of the 2 Resistance Bands (No.

  • Page 6: Important Electrical Information

    IMPORTANT ELECTRICAL INFORMATION IMPORTANT NOTE: This machine requires a power source of 110 Volts in order to properly operate. For your safety, as well as the safety of others, please verify that the power source is correct before powering the machine.

  • Page 7: Battery Replacement

    BATTERY REPLACEMENT Battery Cover Battery CR2025 CR2025 Fig.A Fig.B Fig.C BATTERY REPLACEMENT: 1. Use a coin to insert into the groove on the battery cover, turn the battery cover counterclockwise towards the unlock symbol, then remove the battery cover and remove the old battery.

  • Page 8: The Display Console

    THE DISPLAY CONSOLE KEY FUNCTION DESCRIPTION CONSOLE PANEL CONSOLE FUNCTION DESCRIPTION Q(QUICK SPEED) Speed level 25-50-75-1 START/STOP Start or stop the vibration platform P(PROGRAM) Select P0/P1/P2/P3/P4/P5 program TIME Settle the sport time SPEED +/- Adjust the speed CONTROL PANEL REMOTE CONTROL FUNCTION DESCRIPTION V(VOICE) Beeper voice: soft, loud, off...

  • Page 9: Function Description

    FUNCTION DESCRIPTION User can select the desired program by pressing the “P” button on the console panel or on the remote control (P0, P1, P2, P3, P4, P5). The console panel will show which program the user has chosen. P1 – P5: Pre-set program P0: Manual program P0: MANUAL PROGRAM The machine will be in manual program mode when the machine is turned on.

  • Page 10: Troubleshooting

    TROUBLESHOOTING 1. No lights; does not respond to console panel or remote control. a. Check if the machine is plugged in and switched on. b. Check if the socket works with other electrical products. c. Replace fuse in plug. 2. Remote control does not operate the machine, but the machine does respond to console panel. a.

  • Page 11: Exercise Instruction

    EXERCISE INSTRUCTION Connect one end of Power Cord (No. 33) to the machine, then plug the other end of Power Cord (No. 33) in a suitable power socket. Turn the power switch on the rear of the machine to the “I” position, ensuring the switch illuminates.

  • Page 12: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 13: Parts List

    PARTS LIST Description Specification Console Sticker 136.5*48.6mm Pedal Leather PVC80° Screw M5*10 Up Cover PCB#1 for Screen Display Screw ST3*8 Vibration Board Motor Spindle Unit Screw M8*40 φ8*16*1.5 Flat Gasket Lock-Nut Thread Retainer 16*35*T2.5 V-Belt 4P/EPJ427 Screw M6*25 Insulation Sheet 120*40*T0.25 PCB#2 for Motor Control 110V...
